KD-43X720F&KD-49X720F&KD-49X725F&KD-49X727F&KD-55X720F&KD-55X725F&KD-55X727F
52
1-19-2.Stick HIMERON on the Panel.
For this portion, Himeron tape will be attached by SONY
4.Nonwoven fabric along the panel back
lock with hole right to stick , shall not be
leakage
5.Nonwoven fabric along the panel back
lock with hole left to stick , shall not be
leakage
2.Nonwoven fabric along the
plastic box on the corner to the
attached, shall not be leakage
3.Nonwoven fabric along the
plastic box on the corner to the
attached, shall not be leakage
Item Part Name SONY PN SPEC(L*W*T) Qty Position REMARK
2/3 HEMIRON
4-739-878-01
620mm*8mm*0.25mm 2 Panel Left & Right Side
BY SONY
4/5 HEMIRON
4-739-879-01
535mm*8mm*0.3mm 2 Panel Top Side
To Next Page
