Sony KD-55A8F - 1.3 No Power DDCON;LDO

(Supplementary
information)
1.3 No Power DDCON/LDO
Check item summary
Board IC Ref Voltage supply Output ref. Enable pin Enable source Fuse Vcc ref.
BM2A IC402 +5V_MAIN/+5V_AUDIO C430 R455 P-on u-com IC401 #pin13 F400 C423
BM2A IC403 +3.3V_MAIN/+3.3V_AUDIO C445 R465 P-on u-com IC401 #pin13 F401 C436
BM2A IC405 +1.8V_TU C463 IC405 #PIN5 P-on u-com IC401 #pin12 F403 C461
BM2A IC601 +1.5V_DDR C609 C605 R603 (3.3V or 5V) - C602
BM2A IC602 +1.05V_M2_STBY C611 IC602 #PIN3 C610 (+3.3V _STBY) - C610
BM2A IC603 +1.05V_M2_A_1 C613 IC603 #PIN3 P-on u-com IC401 #pin13 - C612
BM2A IC604 +1.0V_M2 C625 R623 P-on u-com IC401 #pin12 F600 C618
BM2A IC605 +1.05V_M2_ST_ET C631 IC605 #PIN3 M2 IC1000 #AP34 - C630
BM2A IC606 +1.05V_M2_A_2 C633 IC606 #PIN3 P-on u-com IC401 #pin13 - C632
BM2A IC607 VCC3IO_EMMC (1.8V) C635 IC607 #PIN3 P-on u-com IC401 #pin13
-
C634
BM2A IC4001 +1.5V_BE C4007 IC4001 #PIN5 P-on u-com IC401 #pin13 F4000 C4005
BM2A IC4002 +1.1V_BE C4014 IC4002 #PIN5 P-on u-com IC401 #pin13 F4001 C4012
BM2A IC4003 +1.0V_BE C4027 R4020 P-on u-com IC401 #pin12 F4002 C4020
BM2A IC4004 +1.8V_BE C4001 IC4004 #PIN3 P-on u-com IC401 #pin13 - C4000
