Sony KF-E50A10 - Connecting Antenna and VCR

14
GB
3: Connecting an antenna/VCR
A
Antenna cable (not supplied)
Or
To 8 VHF/UHF
(antenna)
1
Rear of the TV
L
(
MONO
)
R
L
P
R/CR
Y
1312
PB/CB
R
L
R
S
S
VIDEO
VIDEO IN
VIDEO OUT
AUDIO
R L
To 8 VHF/UHF
(antenna)
VCR
Antenna cable
(not supplied)
To antenna
output
To video and
audio outputs
Audio/Video cable
(not supplied)
To S video
output
S video cable
(not supplied)
To 1
(S video input)
To t1/3 (video input)
L (MONO) (audio input)
R (audio input)
l: Signal flow
