4-6. SCREW LEGEND (KLV-26M400A/32M400A ONLY)
KVL-26M400A
P/N DISCRIPTION REMARKS TOTAL
2-580-640-01 SCREW, +BVTP2 4X16
REAR COVER-14 MAIN BRKT-1 UNDER COVER-1 SPINE-2 LCD-2 BOTTOM FRAME-2 22
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
HM3/LIGHT GUIDE-2 RC-2 CENTER CAB-4 VESA-2 10
2-580-608-01 SCREW, +PSW M5X16
REAR COVER-1 STAND-3 STAND PLATE-4 8
2-580-607-01 SCREW, +PSW M5X12
STAND NECK-5 5
2-580-606-01 SCREW, +PSW M5X8
(none) 0
2-580-602-01 SCREW, +PSW M4X12
(none) 0
2-580-614-01 SCREW, +K M3X8
STAND EDGE-2 2
2-580-644-01 SCREW, +KTP2 3X8
STAND PLATE-14 14
2-580-600-01 SCREW, +PSW M4X8
BOTTOM FRAME-4 VESA TOP-2 SPINE -2 8
2-580-591-01 SCREW, +PSW M3X5
TERMINAL-2 2
2-580-629-01 SCREW, +BVST 3X8
LVDS-1 RF BRKET-2 BG2A-7 MAIN BRKT-1 11
2-674-965-41 SCREW, +PSW 3SG
G1-4 4
2-580-628-01 SCREW, +BVST 3X6
(none) 0
2-580-654-01 SCREW, +PWTP2 4X16
LCD-1 1
2-580-626-01 SCREW, SP 4-4O UNC
TERMINAL-2 2
KVL-32M400A
P/N DISCRIPTION REMARKS TOTAL
2-580-640-01 SCREW, +BVTP2 4X16
REAR COVER-15 MAIN BRKT-1 UNDER COVER-1 SPINE L-1 SPINE R-1 LCD-2 BOTTOM FRAME-2 23
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
HM3/LIGHT GUIDE-2 RC-2 CENTER CAB-4 8
2-580-608-01 SCREW, +PSW M5X16
REAR COVER-1 STAND-3 STAND PLATE-4 8
2-580-607-01 SCREW, +PSW M5X12
STAND NECK-5 5
2-580-606-01 SCREW, +PSW M5X8
(none) 0
2-580-602-01 SCREW, +PSW M4X12
(none) 0
2-580-614-01 SCREW, +K M3X8
STAND EDGE-2 2
2-580-644-01 SCREW, +KTP2 3X8
STAND PLATE-14 14
2-580-600-01 SCREW, +PSW M4X8
BOTTOM FRAME-4 VESA BOTTOM-2 VESA TOP-2 SPINE R-3 SPINE L-2 13
2-580-591-01 SCREW, +PSW M3X5
TERMINAL-2 2
2-580-629-01 SCREW, +BVST 3X8
LVDS-1 RF BRKET-2 BG2A-7 MAIN BRKT-4 14
2-674-965-41 SCREW, +PSW 3SG
G1-4 4
2-580-628-01 SCREW, +BVST 3X6
(none) 0
2-580-654-01 SCREW, +PWTP2 4X16
(none) 0
2-580-626-01 SCREW, SP 4-4O UNC
TERMINAL-2 2
