4-7. SCREW LEGEND (KLV-37M400A/40M400A ONLY)
KVL-37M400A
P/N DISCRIPTION REMARKS TOTAL
2-580-640-01 SCREW, +BVTP2 4X16
REAR COVER-16 MAIN BRKT-1 UNDER COVER-1 SPINE-2 LCD-2 BOTTOM FRAME-2 24
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
HM3/LIGHT GUIDE-2 RC-2 CENTER CAB-4 8
2-580-608-01 SCREW, +PSW M5X16
REAR COVER-4 STAND-3 STAND PLATE-4 11
2-580-607-01 SCREW, +PSW M5X12
STAND NECK-5 5
2-580-606-01 SCREW, +PSW M5X8
SPINE-6 6
2-580-602-01 SCREW, +PSW M4X12
STAND NECK-2 2
2-580-614-01 SCREW, +K M3X8
(none) 0
2-580-644-01 SCREW, +KTP2 3X8
STAND PLATE-14 STAND EDGE-2 16
2-580-600-01 SCREW, +PSW M4X8
VESA BOTTOM-6 VESA TOP-4 G2-1 11
2-580-591-01 SCREW, +PSW M3X5
TERMINAL-2 2
2-580-629-01 SCREW, +BVST 3X8
LVDS-1 RF BRKET-2 BG2A-7 MAIN BRKT-3 G2-6 19
2-674-965-41 SCREW, +PSW 3SG
(none) 0
2-580-628-01 SCREW, +BVST 3X6
(none) 0
2-580-654-01 SCREW, +PWTP2 4X16
(none) 0
2-580-626-01 SCREW, SP 4-4O UNC
TERMINAL-2 2
KVL-40M400A
P/N DISCRIPTION REMARKS TOTAL
2-580-640-01 SCREW, +BVTP2 4X16
REAR COVER-15 MAIN BRKT-2 UNDER COVER-1 SPINE-2 LCD-2 BOTTOM FRAME-4 26
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
HM3/LIGHT GUIDE-2 RC-2 CENTER CAB-4 8
2-580-608-01 SCREW, +PSW M5X16
REAR COVER-4 STAND-3 STAND PLATE-4 11
2-580-607-01 SCREW, +PSW M5X12
STAND NECK-5 5
2-580-606-01 SCREW, +PSW M5X8
BOTTOM VESA-4 TOP VESA-4 8
2-580-602-01 SCREW, +PSW M4X12
STAND NECK-2 2
2-580-614-01 SCREW, +K M3X8
(none) 0
2-580-644-01 SCREW, +KTP2 3X8
STAND PLATE-14 STAND EDGE-2 16
2-580-600-01 SCREW, +PSW M4X8
SPINE-6 6
2-580-591-01 SCREW, +PSW M3X5
TERMINAL-2 2
2-580-629-01 SCREW, +BVST 3X8
(none) 0
2-674-965-41 SCREW, +PSW 3SG
(none) 0
2-580-628-01 SCREW, +BVST 3X6
LVDS-1 RF BRKET-2 BG2A-7 MAIN BRKT-4 IP5Z-6 20
2-580-654-01 SCREW, +PWTP2 4X16
(none) 0
2-580-626-01 SCREW, SP 4-4O UNC
TERMINAL-2 2
