KLV-26M400A/32M400A/37M400A/40M400A
KLV-26M400A/32M400A/37M400A/40M400A
65
REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
CONNECTOR
* CN2000 1-819-461-11 HEADER ASSEMBLY FOR PWB
CN3003 1-779-331-51 CONNECTOR, FFC/FPC 14P
CN3004 1-779-936-51 CONNECTOR, FFC/FPC 18P
* CN3008 1-820-188-11 HEADER ASSEMBLY (PRINT PWB) 11P
CN3500 1-820-192-11 HEADER ASSEMBLY (PRINT PWB) 15P
* CN4001 1-820-550-11 HEADER ASSEMBLY FOR PWB
CN4002 1-819-463-11 HEADER ASSEMBLY FOR PWB
* CN4003 1-820-182-11 HEADER ASSEMBLY (PRINT PWB)
* CN4500 1-818-656-21 HEADER ASSEMBLY 30P
DIODE
D1000 6-501-758-01 DIODE MAZ8100G0LS0
D1001 6-501-758-01 DIODE MAZ8100G0LS0
D1002 6-501-758-01 DIODE MAZ8100G0LS0
D1008 6-501-758-01 DIODE MAZ8100G0LS0
D1012 6-501-758-01 DIODE MAZ8100G0LS0
! D2014 6-501-756-01 DIODE MAZ8091GMLS0
D2018 6-501-732-01 DIODE MAZ8056G0LS0
D2019 6-501-732-01 DIODE MAZ8056G0LS0
D2020 6-501-732-01 DIODE MAZ8056G0LS0
D2021 6-501-732-01 DIODE MAZ8056G0LS0
D2022 6-501-734-01 DIODE MAZ8056GMLS0
D3002 8-719-071-87 DIODE MA785-(TX),SO
D3006 6-501-817-01 DIODE MA2J1110GLS0
D3007 8-719-077-59 DIODE 1PS302
D3020 6-501-732-01 DIODE MAZ8056G0LS0
D3021 6-501-732-01 DIODE MAZ8056G0LS0
D3022 6-501-817-01 DIODE MA2J1110GLS0
D4004 6-501-734-01 DIODE MAZ8056GMLS0
D4005 6-501-734-01 DIODE MAZ8056GMLS0
D4006 6-501-657-01 DIODE MA24D5000BS0
D4007 6-501-657-01 DIODE MA24D5000BS0
D4008 6-501-528-01 DIODE 1SMA5915BT3G
D4010 6-501-528-01 DIODE 1SMA5915BT3G
D4011 6-501-734-01 DIODE MAZ8056GMLS0
D4012 6-501-774-01 DIODE MAZ8150G0LS0
D4050 6-501-336-01 DIODE RSX201L-30TE25
D4056 8-719-977-28 DIODE DTZ10B
D5000 6-501-732-01 DIODE MAZ8056G0LS0
D5001 6-501-732-01 DIODE MAZ8056G0LS0
D5002 6-501-732-01 DIODE MAZ8056G0LS0
D5003 8-719-050-38 DIODE M1MA152WK-T1
D5508 6-501-817-01 DIODE MA2J1110GLS0
D5516 6-501-817-01 DIODE MA2J1110GLS0
D5525 6-501-817-01 DIODE MA2J1110GLS0
D5528 6-501-817-01 DIODE MA2J1110GLS0
D5620 6-500-813-01 DIODE MA2SD32008S0
D7003 8-719-058-24 DIODE RB501V-40TE-17
FUSE
! F2000 1-576-958-21 FUSE 4A 24V
F2001 1-576-913-11 FUSE 1.6A 36V
F2002 1-576-646-11 FUSE 0.5A 50V
F3001 1-576-646-11 FUSE 0.5A 50V
! F4001 1-576-603-21 FUSE 3.15A 24V
! F4005 1-576-933-21 FUSE 5A 24V
F4006 1-576-913-11 FUSE 1.6A 36V
! F4050 1-576-603-21 FUSE 3.15A 24V
FERRITE BEAD
FB2006 1-400-089-21 FERRITE 0μH
FB2007 1-400-089-21 FERRITE 0μH
FB2008 1-400-089-21 FERRITE 0μH
FB2009 1-400-089-21 FERRITE 0μH
FB2012 1-400-807-21 FERRITE 0μH
FB2015 1-400-212-22 FERRITE 0μH
FB2016 1-400-110-21 FERRITE 0μH
FB2017 1-400-807-21 FERRITE 0μH
FB2018 1-400-807-21 FERRITE 0μH
FB2019 1-400-807-21 FERRITE 0μH
FB4001 1-400-089-21 FERRITE 0μH
FB4003 1-400-089-21 FERRITE 0μH
FB4004 1-400-794-21 FERRITE 0μH
FB4005 1-500-922-11 FERRITE 0μH
FB4008 1-400-591-22 FERRITE 0μH
FB4009 1-400-591-22 FERRITE 0μH
FB4011 1-400-591-22 FERRITE 0μH
FB4050 1-400-794-21 FERRITE 0μH
FB4051 1-400-794-21 FERRITE 0μH
FB4055 1-400-089-21 FERRITE 0μH
FB4056 1-414-445-11 FERRITE 0μH
FB4058 1-400-089-21 FERRITE 0μH
FB4501 1-469-669-21 FERRITE 0μH
FB4701 1-400-794-21 FERRITE 0μH
FB4702 1-400-110-21 FERRITE 0μH
BG2A
