Sony KLV-26M400A - Page 67

KLV-26M400A/32M400A/37M400A/40M400A
KLV-26M400A/32M400A/37M400A/40M400A
67
REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
J5000 1-821-013-11 D SUB CONNECTOR
J5502 1-821-931-11 HDMI CONNECTOR
J5503 1-821-931-11 HDMI CONNECTOR
COIL
L2009 1-469-555-21 INDUCTOR 10μH
L2010 1-469-555-21 INDUCTOR 10μH
L2011 1-469-555-21 INDUCTOR 10μH
L2015 1-469-555-21 INDUCTOR 10μH
L2016 1-481-083-11 INDUCTOR 22μH
L2017 1-412-058-11 INDUCTOR 10μH
L2022 1-457-429-11 INDUCTOR 22μH
L2023 1-457-429-11 INDUCTOR 22μH
L2024 1-457-429-11 INDUCTOR 22μH
L2025 1-457-429-11 INDUCTOR 22μH
L3002 1-400-794-21 FERRITE 0μH
L4001 1-457-195-11 INDUCTOR 4.7μH
L4002 1-457-195-11 INDUCTOR 4.7μH
L4051 1-416-740-11 INDUCTOR 10μH
L4053 1-424-922-21 INDUCTOR 10μH
L4055 1-481-081-11 INDUCTOR 47μH
L4056 1-416-740-11 INDUCTOR 10μH
L4500 1-456-844-11 INDUCTOR 0μH
L4502 1-456-844-11 INDUCTOR 0μH
L4504 1-456-844-11 INDUCTOR 0μH
L4505 1-400-177-21 FERRITE 0μH
L4701 1-400-794-21 FERRITE 0μH
L4800 1-469-557-21 INDUCTOR 22μH
L4900 1-400-794-21 FERRITE 0μH
L4901 1-400-794-21 FERRITE 0μH
L7001 1-416-344-11 INDUCTOR 10μH
L7008 1-469-555-21 INDUCTOR 10μH
L7011 1-469-555-21 INDUCTOR 10μH
L7013 1-469-555-21 INDUCTOR 10μH
L7015 1-469-555-21 INDUCTOR 10μH
L7018 1-469-557-21 INDUCTOR 22μH
IC LINK
! PS5000 1-576-646-11 FUSE 0.5A 50V
TRANSISTOR
Q2006 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2007 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q2008 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q2009 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2010 8-729-013-28 TRANSISTOR HN1B01FU-TE85R
Q2012 6-551-271-01 TRANSISTOR RT3AMMM
Q2013 6-551-271-01 TRANSISTOR RT3AMMM
Q2016 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2017 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2018 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q2019 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q2020 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q2023 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2024 8-729-028-91 TRANSISTOR DTA144EUA-T106
Q2025 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q2026 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q2029 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2030 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2031 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2032 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q2045 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q2046 6-551-677-01 TRANSISTOR RTAN140M-T111-1
Q3001 6-551-387-01 TRANSISTOR SSM6N16FU
Q3002 6-551-420-01 TRANSISTOR RT1N151M-TP-1
Q3003 8-729-028-74 TRANSISTOR DTA114TUA-T106
Q3004 8-729-013-28 TRANSISTOR HN1B01FU-TE85R
Q3005 8-729-028-74 TRANSISTOR DTA114TUA-T106
Q3006 6-550-260-01 TRANSISTOR RT1N237M-TP-1
Q3007 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q3008 6-551-424-01 TRANSISTOR RT1P151M-TP-1
Q4005 6-550-828-01 TRANSISTOR RSQ035P03TR
Q4006 6-550-828-01 TRANSISTOR RSQ035P03TR
Q4007 6-550-355-01 TRANSISTOR RTQ045N03TR
Q4008 6-550-355-01 TRANSISTOR RTQ045N03TR
Q4011 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q4012 8-729-054-36 TRANSISTOR UPA1716G-E2
Q4014 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q4015 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q4016 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q4017 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q4020 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q4021 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q4800 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
