REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
IC
IC6100 6-707-749-01 IC CXD9841P
IC6101 6-711-947-01 IC MM1431CURE
! IC6200 6-708-801-01 IC MIP2H2
IC6250 6-709-442-01 IC MM1530ATT
IC6302 6-709-499-01 IC RT9H301C-T112-1
IC6500 6-712-651-01 IC R2A20112DD#U0
IC6702 6-702-877-01 IC LD1117S50
IC6703 6-705-660-01 IC LM339DT(A)
CHIP CONDUCTOR
JR6001 1-216-296-11 SHORT CHIP
JR6002 1-216-296-11 SHORT CHIP
JR6003 1-216-296-11 SHORT CHIP
JR6004 1-216-296-11 SHORT CHIP
JR6005 1-216-296-11 SHORT CHIP
JR6006 1-216-295-91 SHORT CHIP
JR6007 1-216-296-11 SHORT CHIP
JR6008 1-216-295-91 SHORT CHIP
JR6009 1-216-296-11 SHORT CHIP
JR6010 1-216-295-91 SHORT CHIP
JR6011 1-216-295-91 SHORT CHIP
JR6012 1-216-296-11 SHORT CHIP
JR6013 1-216-296-11 SHORT CHIP
JR6014 1-216-864-11 SHORT CHIP
JR6015 1-216-296-11 SHORT CHIP
JR6016 1-216-295-91 SHORT CHIP
JR6017 1-216-296-11 SHORT CHIP
JR6018 1-216-295-91 SHORT CHIP
JR6019 1-216-295-91 SHORT CHIP
JR6020 1-216-296-11 SHORT CHIP
JR6021 1-216-295-91 SHORT CHIP
JR6101 1-216-295-91 SHORT CHIP
JR6102 1-216-296-11 SHORT CHIP
JR6103 1-216-295-91 SHORT CHIP
JR6104 1-216-296-11 SHORT CHIP
JR6105 1-216-295-91 SHORT CHIP
JR6106 1-216-295-91 SHORT CHIP
JR6151 1-216-296-11 SHORT CHIP
JR6152 1-216-295-91 SHORT CHIP
JR6153 1-216-296-11 SHORT CHIP
JR6154 1-216-296-11 SHORT CHIP
JR6155 1-216-296-11 SHORT CHIP
JR6156 1-216-295-91 SHORT CHIP
JR6157 1-216-296-11 SHORT CHIP
JR6158 1-216-296-11 SHORT CHIP
COIL
L6000 1-457-513-11 LINE FILTER COIL
L6001 1-457-472-11 LINE FILTER COIL
L6151 1-406-657-11 INDUCTOR 4.7μH
L6400 1-414-183-41 INDUCTOR 10μH
L6550 1-457-626-11 INDUCTOR 260μH
L6600 1-406-977-21 INDUCTOR 100μH
L6601 1-419-622-11 COIL, LINE FILTER
PHOTO COUPLER
PH6100 6-600-671-01 PC123Y22FZW
PH6200 6-600-671-01 PC123Y22FZW
PH6300 6-600-671-01 PC123Y22FZW
PH6302 6-600-671-01 PC123Y22FZW
TRANSISTOR
! Q6100 6-551-302-01 TRANSISTOR 2SK3561(LBS1SONY,Q
! Q6101 6-551-302-01 TRANSISTOR 2SK3561(LBS1SONY,Q
Q6300 6-551-678-01 TRANSISTOR 2SA1364-T111-1DE
Q6302 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6303 6-551-714-01 TRANSISTOR INK0001AC1-T112A-1
Q6304 6-551-714-01 TRANSISTOR INK0001AC1-T112A-1
Q6305 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q6306 6-551-865-01 TRANSISTOR RT1P14BC-TP-1
Q6307 6-551-866-01 TRANSISTOR RT1N14BC-TP-1
Q6400 6-551-866-01 TRANSISTOR RT1N14BC-TP-1
Q6402 6-551-865-01 TRANSISTOR RT1P14BC-TP-1
Q6403 6-551-866-01 TRANSISTOR RT1N14BC-TP-1
Q6404 6-551-866-01 TRANSISTOR RT1N14BC-TP-1
Q6500 6-551-678-01 TRANSISTOR 2SA1364-T111-1DE
Q6502 6-551-678-01 TRANSISTOR 2SA1364-T111-1DE
Q6503 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q6504 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6505 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6507 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
! Q6551 6-551-336-01 TRANSISTOR 2SK3934(LBS1SONY.Q
! Q6552 6-551-336-01 TRANSISTOR 2SK3934(LBS1SONY.Q
Q6600 6-551-678-01 TRANSISTOR 2SA1364-T111-1DE
Q6601 6-551-678-01 TRANSISTOR 2SA1364-T111-1DE
! Q6602 6-551-713-01 TRANSISTOR 2SK3569(LBS1SONY.Q
Q6603 6-551-713-01 TRANSISTOR 2SK3569(LBS1SONY.Q
IP5Z
