Sony MDS-JA20ES Service Manual

– 17 –
TRAY ASS’Y
2 two screws
(P2.6
× 6)
2 two screws
(P2.6
× 6)
3 bracket (top)
4 three gears
(top)
8 Remove the tray assembly
in the arrow direction
B .
1 Rotate the pully gear in the arrow
direction
A , and pull out the tray
assembly.
5 screw
(P2.6
× 6)
6 stopper
(shaft B
)
4 three gears
(top)
7 shaft
A
B
• NOTE FOR INSTALLATION
slider assembly
When attaching the tray assembly, first move the slider
assembly in the arrow direction
B and set pin at the
position shown.
When attaching gear (top) (two in front),
pull the tray assembly in the arrow direction
A
completely, and position racks (L), (R) and
slider (D) assembly as shown in the figure.
slider assembly
slider (D)
assembly
tray
assembl
y
pin
rack (L)
gear (top)
marking
slider (D)
assembly
B
A
