Sony MDS-JA20ES Service Manual

– 93 –
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
AC
ANALOG VOLUME AU
* 1-669-294-11 AC BOARD
*********
< CAPACITOR >
! C720 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C721 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C722 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C723 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C724 1-113-925-11 CERAMIC 0.01uF 20% 250V
! C725 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN702 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN705 1-564-321-11 PIN, CONNECTOR 2P
< GROUND PLATE >
* EP701 4-870-539-00 PLATE, GROUND
< LINE FILTER >
! LF700 1-424-485-11 FILTER, LINE
************************************************************
* 1-669-293-11 ANALOG VOLUME BOARD
*********************
< CONNECTOR >
* CN760 1-564-522-11 PLUG, CONNECTOR 7P
< RESISTOR >
R765 1-249-462-11 CARBON 22K 5% 1/4W
R766 1-249-462-11 CARBON 22K 5% 1/4W
< VARIABLE RESISTOR >
RV760 1-225-646-11 RES, VAR 20K/20K (ANALOG REC LEVEL)
************************************************************
* A-4724-135-A AU BOARD, COMPLETE (US, Canadian)
* A-4724-144-A AU BOARD, COMPLETE (AEP, UK)
*******************
< CAPACITOR >
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-126-933-11 ELECT 100uF 20% 16V
C103 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-124-994-11 ELECT 100uF 20% 10V
C105 1-124-995-11 ELECT 220uF 20% 10V
C106 1-164-159-11 CERAMIC 0.1uF 50V
C107 1-130-475-00 MYLAR 0.0022uF 5% 50V
C108 1-130-475-00 MYLAR 0.0022uF 5% 50V
C109 1-162-286-31 CERAMIC 220PF 10% 50V
C110 1-126-049-11 ELECT 22uF 20% 25V
C111 1-162-286-31 CERAMIC 220PF 10% 50V
C112 1-126-049-11 ELECT 22uF 20% 25V
C113 1-162-203-31 CERAMIC 15PF 5% 50V
C114 1-162-203-31 CERAMIC 15PF 5% 50V
C115 1-164-159-11 CERAMIC 0.1uF 50V
C116 1-164-159-11 CERAMIC 0.1uF 50V
C117 1-126-049-11 ELECT 22uF 20% 25V
C118 1-126-049-11 ELECT 22uF 20% 25V
C119 1-126-049-11 ELECT 22uF 20% 25V
C120 1-164-159-11 CERAMIC 0.1uF 50V
C121 1-164-159-11 CERAMIC 0.1uF 50V
C122 1-126-024-11 ELECT 220uF 20% 25V
C123 1-164-159-11 CERAMIC 0.1uF 50V
C124 1-126-022-11 ELECT 47uF 20% 25V
C125 1-126-023-11 ELECT 100uF 20% 25V
C126 1-126-023-11 ELECT 100uF 20% 25V
C128 1-126-023-11 ELECT 100uF 20% 25V
C129 1-126-023-11 ELECT 100uF 20% 25V
C130 1-110-335-11 MYLAR 100PF 5% 50V
C131 1-110-335-11 MYLAR 100PF 5% 50V
C132 1-126-022-11 ELECT 47uF 20% 25V
C134 1-164-159-11 CERAMIC 0.1uF 50V
C135 1-164-159-11 CERAMIC 0.1uF 50V
C137 1-126-020-81 ELECT 22uF 20% 50V
C138 1-126-020-81 ELECT 22uF 20% 50V
C139 1-162-294-31 CERAMIC 0.001uF 10% 50V
C140 1-162-199-31 CERAMIC 10PF 5% 50V
