Sony MDS-JA20ES Service Manual

– 94 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C141 1-162-282-31 CERAMIC 100PF 10% 50V
C142 1-162-282-31 CERAMIC 100PF 10% 50V
C143 1-164-159-11 CERAMIC 0.1uF 50V
C200 1-162-294-31 CERAMIC 0.001uF 10% 50V
C201 1-162-215-31 CERAMIC 47PF 5% 50V
C202 1-164-159-11 CERAMIC 0.1uF 50V
C203 1-164-159-11 CERAMIC 0.1uF 50V
C204 1-164-159-11 CERAMIC 0.1uF 50V
C206 1-126-933-11 ELECT 100uF 20% 16V
C207 1-126-933-11 ELECT 100uF 20% 16V
C209 1-164-159-11 CERAMIC 0.1uF 50V
C212 1-124-995-11 ELECT 220uF 20% 10V
C213 1-164-159-11 CERAMIC 0.1uF 50V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-124-995-11 ELECT 220uF 20% 10V
C216 1-124-995-11 ELECT 220uF 20% 10V
C217 1-164-159-11 CERAMIC 0.1uF 50V
C218 1-164-159-11 CERAMIC 0.1uF 50V
C219 1-124-995-11 ELECT 220uF 20% 10V
C220 1-164-159-11 CERAMIC 0.1uF 50V
C221 1-164-159-11 CERAMIC 0.1uF 50V
C222 1-124-995-11 ELECT 220uF 20% 10V
C223 1-164-159-11 CERAMIC 0.1uF 50V
C224 1-162-199-31 CERAMIC 10PF 5% 50V
C225 1-162-199-31 CERAMIC 10PF 5% 50V
C226 1-136-157-00 FILM 0.022uF 5% 50V
C227 1-136-157-00 FILM 0.022uF 5% 50V
C228 1-126-013-11 ELECT 1000uF 20% 16V
C229 1-164-159-11 CERAMIC 0.1uF 50V
C230 1-126-049-11 ELECT 22uF 20% 25V
C231 1-126-049-11 ELECT 22uF 20% 25V
C232 1-136-165-00 FILM 0.1uF 5% 50V
C233 1-164-159-11 CERAMIC 0.1uF 50V
C234 1-136-165-00 FILM 0.1uF 5% 50V
C235 1-136-165-00 FILM 0.1uF 5% 50V
C236 1-136-165-00 FILM 0.1uF 5% 50V
C237 1-126-022-11 ELECT 47uF 20% 25V
C238 1-126-009-81 ELECT 100uF 20% 16V
C239 1-126-022-11 ELECT 47uF 20% 25V
C240 1-164-159-11 CERAMIC 0.1uF 50V
C241 1-136-165-00 FILM 0.1uF 5% 50V
C242 1-164-159-11 CERAMIC 0.1uF 50V
C243 1-136-165-00 FILM 0.1uF 5% 50V
C244 1-126-009-81 ELECT 100uF 20% 16V
C245 1-126-009-81 ELECT 100uF 20% 16V
C246 1-126-009-81 ELECT 100uF 20% 16V
C247 1-136-154-00 FILM 0.012uF 5% 50V
C248 1-136-154-00 FILM 0.012uF 5% 50V
C249 1-136-154-00 FILM 0.012uF 5% 50V
C250 1-136-154-00 FILM 0.012uF 5% 50V
C251 1-130-479-00 MYLAR 0.0047uF 5% 50V
C252 1-130-479-00 MYLAR 0.0047uF 5% 50V
C253 1-130-479-00 MYLAR 0.0047uF 5% 50V
C254 1-130-479-00 MYLAR 0.0047uF 5% 50V
C255 1-110-339-11 MYLAR 220PF 5% 50V
C256 1-110-339-11 MYLAR 220PF 5% 50V
C257 1-110-339-11 MYLAR 220PF 5% 50V
C258 1-110-339-11 MYLAR 220PF 5% 50V
C259 1-136-818-11 FILM 0.0047uF 5% 100V
C260 1-136-818-11 FILM 0.0047uF 5% 100V
C261 1-136-814-11 FILM 0.001uF 5% 100V
C262 1-136-814-11 FILM 0.001uF 5% 100V
C263 1-125-781-21 ELECT 220uF 20% 35V
C264 1-125-781-21 ELECT 220uF 20% 35V
C265 1-124-699-11 ELECT 220uF 20% 25V
C266 1-124-699-11 ELECT 220uF 20% 25V
C267 1-162-290-31 CERAMIC 470PF 10% 50V
C270 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C271 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C273 1-164-159-11 CERAMIC 0.1uF 50V
C800 1-162-282-31 CERAMIC 100PF 10% 50V
C801 1-162-282-31 CERAMIC 100PF 10% 50V
C802 1-162-294-31 CERAMIC 0.001uF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-162-282-31 CERAMIC 100PF 10% 50V
C805 1-162-294-31 CERAMIC 0.001uF 10% 50V
C806 1-164-159-11 CERAMIC 0.1uF 50V
C807 1-164-159-11 CERAMIC 0.1uF 50V
C808 1-162-294-31 CERAMIC 0.001uF 10% 50V
C809 1-162-205-31 CERAMIC 18PF 5% 50V
C810 1-162-205-31 CERAMIC 18PF 5% 50V
C811 1-164-159-11 CERAMIC 0.1uF 50V
C812 1-164-159-11 CERAMIC 0.1uF 50V
C813 1-162-294-31 CERAMIC 0.001uF 10% 50V
C814 1-162-294-31 CERAMIC 0.001uF 10% 50V
C815 1-162-294-31 CERAMIC 0.001uF 10% 50V
C816 1-162-294-31 CERAMIC 0.001uF 10% 50V
C817 1-131-347-00 TANTALUM 1uF 10% 35V
C818 1-164-159-11 CERAMIC 0.1uF 50V
C819 1-126-925-11 ELECT 470uF 20% 10V
C820 1-164-159-11 CERAMIC 0.1uF 50V
C824 1-162-282-31 CERAMIC 100PF 10% 50V
C825 1-164-159-11 CERAMIC 0.1uF 50V
C827 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN100 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN200 1-564-510-11 PLUG (MICRO CONNECTOR) 6P
CN400 1-770-651-11 CONNECTOR, FFC/FPC 23P
CN501 1-785-374-11 CONNECTOR, FFC/FPC 11P
CN502 1-691-768-31 PLUG (MICRO CONNECTOR) 6P
CN800 1-770-653-11 CONNECTOR, FFC/FPC 25P
CN801 1-785-373-11 CONNECTOR, FFC/FPC 27P
CN802 1-569-490-11 SOCKET, CONNECTOR 3P
< DIODE >
D100 8-719-911-19 DIODE 1SS119
D101 8-719-911-19 DIODE 1SS119
D102 8-719-911-19 DIODE 1SS119
D103 8-719-911-19 DIODE 1SS119
D104 8-719-210-21 DIODE 11EQS04
D201 8-719-911-19 DIODE 1SS119
D202 8-719-210-21 DIODE 11EQS04
D802 8-719-911-19 DIODE 1SS119
D803 8-719-911-19 DIODE 1SS119
