Sony MDS-JA20ES Service Manual

– 95 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D805 8-719-210-21 DIODE 11EQS04
D806 8-719-200-82 DIODE 11ES2
< GROUND PLATE >
* EP200 4-870-539-00 PLATE, GROUND
< IC >
IC100 8-759-426-99 IC CXD8607N-T6
IC101 8-759-352-59 IC CXA8054M
IC102 8-759-390-42 IC uPC24M05AHF
IC103 8-759-712-02 IC NJM2114D
IC200 8-759-498-20 IC CXD8735N-TP
IC203 8-759-371-51 IC CXA8042AS
IC204 8-759-371-51 IC CXA8042AS
IC205 8-759-390-42 IC uPC24M05AHF
IC241 8-759-712-02 IC NJM2114D
IC242 8-759-712-02 IC NJM2114D
IC243 8-759-712-02 IC NJM2114D
IC244 8-759-712-02 IC NJM2114D
IC800 8-759-539-14 IC M30610MCA-260FP
IC801 8-759-242-70 IC TC7WU04F
< JACK >
J100 1-784-430-11 JACK, PIN 4P
(LINE (ANALOG) OUT, LINE (ANALOG) IN)
< COIL >
L100 1-408-405-00 INDUCTOR 4.7uH
L101 1-408-405-00 INDUCTOR 4.7uH
L102 1-408-405-00 INDUCTOR 4.7uH
L200 1-408-405-00 INDUCTOR 4.7uH
L201 1-408-405-00 INDUCTOR 4.7uH
L202 1-408-405-00 INDUCTOR 4.7uH
L203 1-408-405-00 INDUCTOR 4.7uH
L204 1-408-405-00 INDUCTOR 4.7uH
L205 1-408-405-00 INDUCTOR 4.7uH
L206 1-412-473-31 INDUCTOR 0uH
< RESISTOR >
R100 1-259-396-11 CARBON 47 5% 1/6W
R101 1-259-396-11 CARBON 47 5% 1/6W
R102 1-259-396-11 CARBON 47 5% 1/6W
R103 1-259-404-11 CARBON 100 5% 1/6W
R104 1-259-404-11 CARBON 100 5% 1/6W
R105 1-259-404-11 CARBON 100 5% 1/6W
R106 1-259-404-11 CARBON 100 5% 1/6W
R107 1-259-476-11 CARBON 100K 5% 1/6W
R108 1-259-476-11 CARBON 100K 5% 1/6W
R109 1-259-460-11 CARBON 22K 5% 1/6W
R110 1-259-460-11 CARBON 22K 5% 1/6W
R111 1-249-995-11 CARBON 1M 5% 1/4W
R112 1-249-995-11 CARBON 1M 5% 1/4W
R113 1-249-995-11 CARBON 1M 5% 1/4W
R114 1-249-995-11 CARBON 1M 5% 1/4W
R115 1-249-528-91 CARBON 100 5% 1/4W
R116 1-249-528-91 CARBON 100 5% 1/4W
R117 1-259-445-11 CARBON 5.1K 5% 1/6W
R118 1-259-444-11 CARBON 4.7K 5% 1/6W
R119 1-247-887-00 CARBON 220K 5% 1/4W
R120 1-247-887-00 CARBON 220K 5% 1/4W
R121 1-247-807-31 CARBON 100 5% 1/4W
R122 1-247-807-31 CARBON 100 5% 1/4W
R123 1-249-923-11 CARBON 1K 5% 1/4W
R124 1-247-807-31 CARBON 100 5% 1/4W
R125 1-247-807-31 CARBON 100 5% 1/4W
R126 1-249-923-11 CARBON 1K 5% 1/4W
R200 1-249-413-11 CARBON 470 5% 1/4W
R201 1-249-413-11 CARBON 470 5% 1/4W
R202 1-249-413-11 CARBON 470 5% 1/4W
R203 1-259-396-11 CARBON 47 5% 1/6W
R204 1-259-396-11 CARBON 47 5% 1/6W
R205 1-247-807-31 CARBON 100 5% 1/4W
R206 1-247-807-31 CARBON 100 5% 1/4W
R207 1-247-807-31 CARBON 100 5% 1/4W
R208 1-247-807-31 CARBON 100 5% 1/4W
R209 1-247-807-31 CARBON 100 5% 1/4W
R210 1-247-807-31 CARBON 100 5% 1/4W
R211 1-259-416-11 CARBON 330 5% 1/6W
R212 1-259-416-11 CARBON 330 5% 1/6W
R213 1-259-416-11 CARBON 330 5% 1/6W
R214 1-259-416-11 CARBON 330 5% 1/6W
R215 1-259-416-11 CARBON 330 5% 1/6W
R216 1-259-416-11 CARBON 330 5% 1/6W
R217 1-259-416-11 CARBON 330 5% 1/6W
R218 1-259-416-11 CARBON 330 5% 1/6W
R219 1-259-452-11 CARBON 10K 5% 1/6W
R220 1-259-380-11 CARBON 10 5% 1/6W
R221 1-259-380-11 CARBON 10 5% 1/6W
R222 1-259-380-11 CARBON 10 5% 1/6W
R223 1-259-380-11 CARBON 10 5% 1/6W
R224 1-259-436-11 CARBON 2.2K 5% 1/6W
R225 1-259-436-11 CARBON 2.2K 5% 1/6W
R226 1-259-416-11 CARBON 330 5% 1/6W
R227 1-259-412-11 CARBON 220 5% 1/6W
R228 1-259-416-11 CARBON 330 5% 1/6W
R229 1-259-412-11 CARBON 220 5% 1/6W
R230 1-259-380-11 CARBON 10 5% 1/6W
R231 1-259-380-11 CARBON 10 5% 1/6W
R232 1-259-380-11 CARBON 10 5% 1/6W
R233 1-259-380-11 CARBON 10 5% 1/6W
R234 1-259-390-11 CARBON 27 5% 1/6W
R235 1-259-390-11 CARBON 27 5% 1/6W
R236 1-259-390-11 CARBON 27 5% 1/6W
R237 1-259-390-11 CARBON 27 5% 1/6W
R238 1-259-418-11 CARBON 390 5% 1/6W
R239 1-259-418-11 CARBON 390 5% 1/6W
R240 1-259-418-11 CARBON 390 5% 1/6W
R241 1-259-418-11 CARBON 390 5% 1/6W
R242 1-259-452-11 CARBON 10K 5% 1/6W
R243 1-259-452-11 CARBON 10K 5% 1/6W
R244 1-259-452-11 CARBON 10K 5% 1/6W
R245 1-259-452-11 CARBON 10K 5% 1/6W
R246 1-259-452-11 CARBON 10K 5% 1/6W
R247 1-259-452-11 CARBON 10K 5% 1/6W
AU
