Sony MDS-JA20ES Service Manual

– 96 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R248 1-259-452-11 CARBON 10K 5% 1/6W
R249 1-259-452-11 CARBON 10K 5% 1/6W
R250 1-259-428-11 CARBON 1K 5% 1/6W
R251 1-259-428-11 CARBON 1K 5% 1/6W
R252 1-259-428-11 CARBON 1K 5% 1/6W
R253 1-259-428-11 CARBON 1K 5% 1/6W
R254 1-249-520-11 CARBON 47 5% 1/4W
R255 1-249-520-11 CARBON 47 5% 1/4W
R256 1-249-520-11 CARBON 47 5% 1/4W
R258 1-249-520-11 CARBON 47 5% 1/4W
R267 1-249-469-11 CARBON 100K 5% 1/4W
R268 1-249-469-11 CARBON 100K 5% 1/4W
R800 1-249-429-11 CARBON 10K 5% 1/4W
R801 1-249-429-11 CARBON 10K 5% 1/4W
R802 1-249-429-11 CARBON 10K 5% 1/4W
R803 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK)
R804 1-249-429-11 CARBON 10K 5% 1/4W
(US, Canadian)
R806 1-249-429-11 CARBON 10K 5% 1/4W
(US, Canadian)
R807 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK)
R808 1-249-429-11 CARBON 10K 5% 1/4W
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-249-441-11 CARBON 100K 5% 1/4W
R811 1-249-429-11 CARBON 10K 5% 1/4W
R812 1-249-429-11 CARBON 10K 5% 1/4W
R813 1-249-429-11 CARBON 10K 5% 1/4W
R814 1-249-429-11 CARBON 10K 5% 1/4W
R815 1-249-429-11 CARBON 10K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R819 1-247-891-00 CARBON 330K 5% 1/4W
R820 1-249-429-11 CARBON 10K 5% 1/4W
R822 1-249-429-11 CARBON 10K 5% 1/4W
R823 1-249-441-11 CARBON 100K 5% 1/4W
R824 1-249-441-11 CARBON 100K 5% 1/4W
R826 1-249-429-11 CARBON 10K 5% 1/4W
R827 1-249-429-11 CARBON 10K 5% 1/4W
R829 1-249-429-11 CARBON 10K 5% 1/4W
R830 1-249-429-11 CARBON 10K 5% 1/4W
R832 1-249-429-11 CARBON 10K 5% 1/4W
R833 1-249-429-11 CARBON 10K 5% 1/4W
R834 1-247-807-31 CARBON 100 5% 1/4W
R835 1-247-807-31 CARBON 100 5% 1/4W
R836 1-249-429-11 CARBON 10K 5% 1/4W
R837 1-249-429-11 CARBON 10K 5% 1/4W
R838 1-249-438-11 CARBON 56K 5% 1/4W
R839 1-249-417-11 CARBON 1K 5% 1/4W
R840 1-249-429-11 CARBON 10K 5% 1/4W
R841 1-249-429-11 CARBON 10K 5% 1/4W
R842 1-249-429-11 CARBON 10K 5% 1/4W
R843 1-249-429-11 CARBON 10K 5% 1/4W
R844 1-249-429-11 CARBON 10K 5% 1/4W
R845 1-249-429-11 CARBON 10K 5% 1/4W
R846 1-249-429-11 CARBON 10K 5% 1/4W
R847 1-249-429-11 CARBON 10K 5% 1/4W
R848 1-249-429-11 CARBON 10K 5% 1/4W
R854 1-249-429-11 CARBON 10K 5% 1/4W
R855 1-249-429-11 CARBON 10K 5% 1/4W
R856 1-247-807-31 CARBON 100 5% 1/4W
R857 1-249-807-81 CARBON 100 5% 1/4W
R858 1-249-807-81 CARBON 100 5% 1/4W
R859 1-249-417-11 CARBON 1K 5% 1/4W
R860 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY200 1-755-188-11 RELAY
< VIBRATOR >
X200 1-579-161-11 VIBRATOR, CRYSTAL (45MHz)
X800 1-767-778-21 VIBRATOR, CERAMIC (7MHz)
X801 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
* A-4724-285-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-125-822-11 TANTALUM 10uF 20% 10V
C102 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-125-822-11 TANTALUM 10uF 20% 10V
C104 1-125-822-11 TANTALUM 10uF 20% 10V
C105 1-163-021-00 CERAMIC CHIP 0.01uF 10% 50V
C106 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C107 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C111 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C112 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C113 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C115 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C116 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C118 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C119 1-125-822-11 TANTALUM 10uF 20% 10V
C121 1-125-822-11 TANTALUM 10uF 20% 10V
C122 1-163-021-00 CERAMIC CHIP 0.01uF 10% 50V
C123 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C124 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C127 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C128 1-163-021-00 CERAMIC CHIP 0.01uF 10% 50V
C129 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C130 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C131 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C132 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C133 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C134 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C135 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C136 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C142 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C143 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C144 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C146 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C152 1-163-038-00 CERAMIC CHIP 0.1uF 25V
AU BD
