– 34 –
5-16. ADJUSTING POINTS AND CONNECTING POINTS
[BD Board] (SIDE A)
Note: It is useful to use the jig. for checking the waveform. (Refer to
Servicing Notes on page 7.)
[BD Board] (SIDE B)
CN110
NOTE
D101
I+3V
IOP
TEO
RF
VC
GND
IC171
IC121
IC101
IC192
CN101
