– 39 –
• Circuit Boards Location
AC board
BD board
PSW board
MOTOR board
HEADPHONE board
FL board
DIGITAL board
POWER board
AU boar
d
RELEASE board
OUT SWITCH board
ANALOG VOLUME board
POSITION SWITCH board
