– 42 –
• Semiconductor
Location
(Conductor Side)
Ref. No. Location
IC101 G-5
IC121 C-5
IC124 C-6
IC152 E-2
IC181 C-2
IC192 B-1
Q101 E-6
Q162 E-6
Q163 D-5
Q181 B-2
Q182 B-3
(Page 52)
(Page 58)
