Pin No. Pin Name I/O Function

40 AVDDL —

Power supply terminal (+5V) (for L-ch side D/A converter section, analog system)

Not used (open)

41 L1 O

L-ch PLM signal 1 output terminal Not used (open)

42 VDD2 —

Power supply terminal (+5V) (for L-ch side D/A converter section, digital system)

Not used (open)

43, 44 VDD1 —

Power supply terminal (+5V) (for A/D converter section, digital system)

45 VSS1 —

Ground terminal (for A/D converter section, digital system)

46 TEST2 I

Input terminal for the test (fixed at “L”)

47 TEST3 I

Input terminal for the test (fixed at “L”)

48 VSS1 —

Ground terminal (for A/D converter section, digital system)

49 NU —

Not used (open)

50 NU —

Not used (open)

51 AVSS —

Ground terminal (for A/D converter section, analog system)

52 LVDD —

Power supply terminal (+5V) (for A/D converter section, buffer system)

53 LVSS —

Ground terminal (for A/D converter section, buffer system)

54 REFO O

Reference voltage (+3.3V) output terminal (for A/D converter section)

55 INLM I

L-ch analog signal (+) input terminal

56 INLP I

L-ch analog signal (–) input terminal
