Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
80
AD
< CONNECTOR >
CN301 1-779-279-11 CONNECTOR,FFC(LIF(NON-ZIF)) 11P
CN302 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN303 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
CN304 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D301 8-719-911-19 DIODE 1SS133T-72
D302 8-719-911-19 DIODE 1SS133T-72
D303 8-719-911-19 DIODE 1SS133T-72
D304 8-719-911-19 DIODE 1SS133T-72
D305 8-719-911-19 DIODE 1SS133T-72
D306 8-719-911-19 DIODE 1SS133T-72
D307 8-719-911-19 DIODE 1SS133T-72
D308 8-719-911-19 DIODE 1SS133T-72
D309 8-719-210-21 DIODE 11EQS04-TA2B
D310 8-719-210-21 DIODE 11EQS04-TA2B
D311 8-719-210-21 DIODE 11EQS04-TA2B
< IC >
IC302 8-759-686-36 IC AK5383VF
IC304 8-759-604-35 IC M5F78M05L
IC305 8-759-712-02 IC NJM2114D
IC306 8-759-712-02 IC NJM2114D
IC307 8-759-712-02 IC NJM2114D
IC308 8-759-712-02 IC NJM2114D
< COIL >
L301 1-408-599-31 INDUCTOR 4.7uH
* L302 1-410-858-21 INDUCTOR 0uH
L303 1-408-599-31 INDUCTOR 4.7uH
< RESISTOR >
R301 1-247-807-31 CARBON 100 5% 1/4W
R302 1-247-807-31 CARBON 100 5% 1/4W
R303 1-247-807-31 CARBON 100 5% 1/4W
R304 1-247-807-31 CARBON 100 5% 1/4W
R305 1-247-807-31 CARBON 100 5% 1/4W
R306 1-249-429-11 CARBON 10K 5% 1/4W
R307 1-249-429-11 CARBON 10K 5% 1/4W
R311 1-249-504-11 CARBON 10 5% 1/4W
R312 1-249-504-11 CARBON 10 5% 1/4W
R313 1-249-504-11 CARBON 10 5% 1/4W
R314 1-249-504-11 CARBON 10 5% 1/4W
R315 1-249-947-11 CARBON 10K 5% 1/4W
R316 1-249-947-11 CARBON 10K 5% 1/4W
R317 1-249-947-11 CARBON 10K 5% 1/4W
R318 1-249-947-11 CARBON 10K 5% 1/4W
R319 1-249-947-11 CARBON 10K 5% 1/4W
R320 1-249-947-11 CARBON 10K 5% 1/4W
R321 1-249-953-11 CARBON 18K 5% 1/4W
R322 1-249-953-11 CARBON 18K 5% 1/4W
R323 1-249-941-11 CARBON 5.6K 5% 1/4W
R324 1-249-941-11 CARBON 5.6K 5% 1/4W
R325 1-249-469-11 CARBON 100K 5% 1/4W
R326 1-249-469-11 CARBON 100K 5% 1/4W
R327 1-249-923-11 CARBON 1K 5% 1/4W
R328 1-249-923-11 CARBON 1K 5% 1/4W
R329 1-249-995-11 CARBON 1M 5% 1/4W
R330 1-249-995-11 CARBON 1M 5% 1/4W
R331 1-249-995-11 CARBON 1M 5% 1/4W
R332 1-249-995-11 CARBON 1M 5% 1/4W
R333 1-249-947-11 CARBON 10K 5% 1/4W
R334 1-249-947-11 CARBON 10K 5% 1/4W
************************************************************
A-4725-174-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-125-822-11 TANTALUM 10uF 20.00% 10V
C102 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C103 1-125-822-11 TANTALUM 10uF 20.00% 10V
C104 1-125-822-11 TANTALUM 10uF 20.00% 10V
C105 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C106 1-163-275-11 CERAMIC CHIP 0.001uF 5.00% 50V
C107 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C108 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C109 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C111 1-164-344-11 CERAMIC CHIP 0.068uF 10.00% 25V
C112 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C113 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C115 1-164-489-11 CERAMIC CHIP 0.22uF 10.00% 16V
C116 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C118 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C119 1-125-822-11 TANTALUM 10uF 20.00% 10V
C121 1-125-822-11 TANTALUM 10uF 20.00% 10V
C122 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C123 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C124 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C127 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C128 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C129 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C130 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C131 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C132 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C133 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C134 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C135 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C136 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C142 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C143 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C144 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C146 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C152 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C153 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C156 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C158 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-104-601-11 ELECT CHIP 10uF 20.00% 10V
C161 1-104-601-11 ELECT CHIP 10uF 20.00% 10V
C163 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C164 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C167 1-163-038-11 CERAMIC CHIP 0.1uF 25V
BD
