[Checks before Part Replacement and Adjustment]
Cause of faulty can be approximately located by performing the following checks before starting the repair work. Refer to Section “5.
Electrical Adjustment” the check procedure.
Note: The judgment criterion is shown for the purpose of judging if the performance is acceptable or not. This is not the specification value for adjustment.
Use the specification value for adjustment when the MDS-JA333ES is going to be adjusted.
Laser power check
(Refer to section 5-6-2.)
Traverse check
(Refer to section 5-6-3.)
Focus bias check
(Refer to section 5-6-4.)
C PLAY check
(Refer to section 5-6-5.)
Self record/playback check
(Refer to section 5-6-6.)
Temperature compensation
offset check
(Refer to section 5-6-1.)
Judgment criterion(NG when the measurement
value is out of the specification value)
• 0.9 mW power
Specification value: 0.8 to 0.96 mW
• 6.2 mW power
Specification value: 6.0 to 6.4 mW
• Iop (when 7 mW)
The Iop value that is shown on the optical
pick-up: +/- 4 mA
• Traverse waveform
Specification value: Offset 5% or less
• Checking the error rate
Specification value: All points of a and b
CI error 220 or less
AD error 2 or less
• Checking the error rate
Specification value:
a. When using the test disc (MDW-74/AU-1)
CI error 50 or less
AD error 2 or less
b. When using the check disc (TDYS-1)
CI error 20 or less
• Checking the error rate in C PLAY
Specification value:
CI error 50 or less
AD error 2 or less
• NG when “T=@@(##)(NG” appears
(@@ and ## are arbitrary numbers.)
Remedial measure in case of NG
• Cleaning the optical pick-up
• Readjustment
• Replacing the optical pick-up
• Replacing the optical pick-up
• Replacing the optical pick-up
• Replacing the optical pick-up
• Replacing the optical pick-up
In case of NG all the time:
• Replacing the overwrite head
• Check disconnection of the circuits around
the overwrite head
In case of intermittent NG:
• Check deformation of overwrite head
• Check mechanism around the sled
• Check disconnection of the circuits around
the D101 (BD board)
• Check signals around the IC101, IC121,
CN102 and CN103 (BD board)
