— 10 —
3-3. BD BOARD
3-4. SUB CHASSIS
2
Flat type wire (15 core)
1
Flexible board
(Over write head
)
3
Screw (BVTT2
×
4)
5
BD board
4
OP relay flexible board
1
Two step screws
3
Two insulators
2
Two step screws
4
Two insulators
5
Sub chassis
Part A
Part A
Part A
NG
OK
Take care so that the part A
may be right position when installing.
