Sony MDX-CA680 - Page 56

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
56
MDX-CA680/CA680X
C63 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(AEP, UK)
C302 1-124-233-11 ELECT 10uF 20% 16V
C305 1-124-589-11 ELECT 47uF 20% 16V
C307 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C331 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C333 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C401 1-124-589-11 ELECT 47uF 20% 16V
C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C404 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C405 1-126-160-11 ELECT 1uF 20% 50V
C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C411 1-126-160-11 ELECT 1uF 20% 50V
C412 1-126-160-11 ELECT 1uF 20% 50V
C413 1-126-160-11 ELECT 1uF 20% 50V
C414 1-126-160-11 ELECT 1uF 20% 50V
C415 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C416 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C421 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C422 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C431 1-124-233-11 ELECT 10uF 20% 16V
C433 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C435 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C441 1-124-233-11 ELECT 10uF 20% 16V
C442 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C445 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C451 1-124-233-11 ELECT 10uF 20% 16V
C453 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C455 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C456 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C461 1-124-233-11 ELECT 10uF 20% 16V
C463 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C465 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C471 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C474 1-124-233-11 ELECT 10uF 20% 16V
C475 1-107-906-11 ELECT 10uF 20% 16V
C476 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C477 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C479 1-124-589-11 ELECT 47uF 20% 16V
C480 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C484 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C501 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(US)
C501 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(AEP, UK)
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C505 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C506 1-162-916-11 CERAMIC CHIP 10PF 0.5PF 50V
(AEP, UK)
C506 1-162-915-11 CERAMIC CHIP 12PF 5% 50V
(US)
C507 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C511 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
MAIN
C512 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C541 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C551 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C553 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C561 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C562 1-126-935-11 ELECT 470uF 20% 16V
C601 1-126-768-11 ELECT 2200uF 20% 16V
C602 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C611 1-107-906-11 ELECT 10uF 20% 16V
C612 1-107-906-11 ELECT 10uF 20% 16V
C613 1-107-906-11 ELECT 10uF 20% 16V
C614 1-107-906-11 ELECT 10uF 20% 16V
C617 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C618 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C621 1-104-665-11 ELECT 100uF 20% 10V
C622 1-125-710-11 DOUBLE LAYER 0.1F 5.5V
C631 1-126-160-11 ELECT 1uF 20% 50V
C651 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C653 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C662 1-107-906-11 ELECT 10uF 20% 16V
C663 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C682 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C714 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN601 1-774-701-11 PIN, CONNECTOR 16P
CN701 1-784-456-11 CONNECTOR, FFC/FPC 14P
CNJ600 1-580-907-31 PLUG, CONNECTOR (BUS CONTROLL IN)
CNP301 1-815-260-11 CONNECTOR, BOAR TO BOARD 30P
< DIODE >
D1 8-719-073-01 DIODE MA111- (K8).S0
D21 8-719-073-01 DIODE MA111- (K8).S0
D22 8-719-073-01 DIODE MA111- (K8).S0
D23 8-719-976-99 DIODE DTZ5.1B (AEP, UK)
D301 8-719-400-20 DIODE MA152WA
D331 8-719-056-83 DIODE UDZ-TE-17-6.8B
D333 8-719-158-15 DIODE RD5.6SB
D471 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D472 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D473 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D474 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D475 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D476 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D477 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D478 8-719-079-97 DIODE CRZ22 (TE85L.SONY)
D479 8-719-073-01 DIODE MA111- (K8).S0
D480 8-719-158-15 DIODE RD5.6SB
D502 8-719-400-18 DIODE MA152WK
D552 8-719-422-64 DIODE MA8062-M
D553 8-719-056-93 DIODE UDZ-TE-17-18B
D554 8-719-072-70 DIODE MA2ZD14001S0
D555 8-719-056-93 DIODE UDZ-TE-17-18B
D558 8-719-801-78 DIODE 1SS184
D560 8-719-073-01 DIODE MA111- (K8).S0
D601 8-719-049-38 DIODE 1N5404TU
D609 8-719-056-83 DIODE UDZ-TE-17-6.8B
D610 8-719-056-65 DIODE 1SS372-TE85L
