Sony MDX-CA680 - Page 57

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
57
MDX-CA680/CA680X
D612 8-719-053-18 DIODE 1SR154-400TE-25
D613 8-719-053-18 DIODE 1SR154-400TE-25
D614 8-719-053-18 DIODE 1SR154-400TE-25
D621 8-719-067-56 DIODE MA112-TX
D665 8-719-820-05 DIODE 1SS181
D701 8-719-978-69 DIODE DTZ-TT11-16B
D703 8-719-056-93 DIODE UDZ-TE-17-18B
D710 8-719-056-83 DIODE UDZ-TE-17-6.8B
D711 8-719-056-83 DIODE UDZ-TE-17-6.8B
D712 8-719-056-83 DIODE UDZ-TE-17-6.8B
D713 8-719-056-83 DIODE UDZ-TE-17-6.8B
D714 8-719-056-83 DIODE UDZ-TE-17-6.8B
D715 8-719-056-83 DIODE UDZ-TE-17-6.8B
D716 8-719-056-83 DIODE UDZ-TE-17-6.8B
D717 8-719-056-83 DIODE UDZ-TE-17-6.8B
D718 8-719-056-83 DIODE UDZ-TE-17-6.8B
D719 8-719-056-83 DIODE UDZ-TE-17-6.8B
< FUSE >
FU601 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) (10A)
< IC >
IC20 8-759-909-71 IC BA4558F-E2 (AEP, UK)
IC51 8-759-492-59 IC SAA6588T-118 (AEP, UK)
IC401 8-759-653-27 IC TDA7402TR
IC501 8-759-830-31 IC MN101C49KTJ (US)
IC501 8-759-830-32 IC MN101C49KTK (AEP, UK)
IC505 8-759-449-89 IC BA8270F-E2
IC601 8-759-661-47 IC BA4908-V3
IC602 8-759-682-69 IC XC61AN4302MR
IC611 8-759-827-14 IC TA8268AH
< JACK >
J10 1-815-185-11 JACK (FM/AM ANTENNA IN))
J561 1-566-822-41 JACK (REMOTE IN)
< SHORT >
JC7 1-216-296-11 SHORT 0
JC10 1-216-296-11 SHORT 0
JC11 1-216-296-11 SHORT 0 (AEP, UK)
JC12 1-216-296-11 SHORT 0
JC13 1-216-296-11 SHORT 0
JC14 1-216-296-11 SHORT 0
JC15 1-216-296-11 SHORT 0
JC16 1-216-296-11 SHORT 0
JC17 1-216-296-11 SHORT 0
JC18 1-216-296-11 SHORT 0
JC19 1-216-296-11 SHORT 0
JC21 1-216-296-11 SHORT 0
JC22 1-216-296-11 SHORT 0
JC23 1-216-296-11 SHORT 0
JC24 1-216-864-11 SHORT 0
JC25 1-216-296-11 SHORT 0
JC26 1-216-296-11 SHORT 0
JC27 1-216-296-11 SHORT 0
JC28 1-216-296-11 SHORT 0
JC29 1-216-296-11 SHORT 0
JC30 1-216-864-11 SHORT 0
JC33 1-216-296-11 SHORT 0
JC34 1-216-296-11 SHORT 0
JC35 1-216-296-11 SHORT 0
JC37 1-216-296-11 SHORT 0
JC41 1-216-296-11 SHORT 0 (AEP, UK)
JC42 1-216-296-11 SHORT 0 (AEP, UK)
JC43 1-216-296-11 SHORT 0 (AEP, UK)
JC44 1-216-296-11 SHORT 0
JC45 1-216-296-11 SHORT 0
JC47 1-216-296-11 SHORT 0
JC48 1-216-864-11 SHORT 0
JC49 1-216-296-11 SHORT 0
JC50 1-216-864-11 SHORT 0
JC51 1-216-296-11 SHORT 0 (AEP, UK)
JC52 1-216-296-11 SHORT 0 (AEP, UK)
JC53 1-216-296-11 SHORT 0
JC101 1-216-295-11 SHORT 0
JC104 1-216-864-11 SHORT 0 (AEP, UK)
JC105 1-216-296-11 SHORT 0 (AEP, UK)
JC106 1-216-864-11 SHORT 0 (US)
JC107 1-216-864-11 SHORT 0 (US)
< COIL >
L500 1-419-476-11 INDUCTOR 250uH
L671 1-410-750-41 INDUCTOR 0.47uH
< JACK >
PJ401 1-774-700-11 JACK, PIN 6P
(BUS AUDIO IN, AUDIO OUT FRONT/REAR)
< TRANSISTOR >
Q21 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (AEP, UK)
Q22 8-729-027-59 TRANSISTOR DTC144EKA-T146
(AEP, UK)
Q331 8-729-019-00 TRANSISTOR 2SD2394-G
Q333 8-729-047-76 TRANSISTOR FMC2A-T148
Q335 8-729-047-76 TRANSISTOR FMC2A-T148
Q336 8-729-920-85 TRANSISTOR 2SD1664-QR
Q431 8-729-920-21 TRANSISTOR DTC314TKH04
Q441 8-729-920-21 TRANSISTOR DTC314TKH04
Q451 8-729-920-21 TRANSISTOR DTC314TKH04
Q461 8-729-920-21 TRANSISTOR DTC314TKH04
Q478 8-729-027-59 TRANSISTOR DTC144EKA-T146
Q479 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q560 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q631 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q651 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q662 8-729-047-76 TRANSISTOR FMC2A-T148
Q663 8-729-047-76 TRANSISTOR FMC2A-T148
Q664 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q665 8-729-106-60 TRANSISTOR 2SB1115A-YQ
Q701 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R9 1-216-817-11 METAL CHIP 470 5% 1/16W
R16 1-216-809-11 METAL CHIP 100 5% 1/16W
R17 1-216-809-11 METAL CHIP 100 5% 1/16W
MAIN
