MHC-V21/V21D
18
Ver. 1.1
2-9. MOTHERBOARD BOARD
8 one screw
(+BVTP 3 u 8)
8 one screw
(+BVTP 3 u 8)
8 one screw
(+BVTP 3 u 8)
8 three screws
(+BVTP 3 u 8)
0 two screws
(+BVTP 3 u 8)
qa heatsink (AMP)
qs MOTHERBOARD
board
2 CN107 (2P)
5 CN001(10P)
3 CN2023
(4P)
7 CN2007
(8P)
9 clamp, (N)
9 clamp,
(N)
9 clamp, (N)
4 CN2024
(2P)
Note : When you install the connector, please install them correctly.
There is a possibility that this machine damages when not
correctly installing it.
Insert is shallow
Insert is straight
to the interior.
connector
Insert is incline
connector
connector
connector
connector connector
OK NG NG
:LUHVHWWLQJ
:LUHVHWWLQJ
1 Remove the wires
from clamp (N).
6 Remove the wires
from clamp (N).
MOTHERBOARD board
MOTHERBOARD board
(V21)
(V21)
(V21)
SYSSET
