Sony MHC-V21 - Chassis Section

49
MHC-V21/V21D
Ver. 1.1
ns
ns
ns
ns
151
152
153
153
front panel section
speaker cabinet section
#1
#1
#1
#1
152
7-4. CHASSIS SECTION
0 151 A-2203-526-A SMPS BOARD, COMPLETE
152 4-558-595-01 STEP SCREW M4
153 4-532-593-02 SCREW (4X13) (TR-184A)
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
ns not supplied
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SYSSET
