7-9. DVD MECHANISM SECTION
(CDM90-DVBU204//M)
Note: If fl exible fl at cable is replaced, install it after bending
it in the same form as that before replacement.
401 A-1896-391-B LOADING COMPLETE ASSY (T)
(including MS-476 board)
402 3-087-599-01 INSULATOR SCREW
403 2-634-618-21 INSULATOR
0
404 A-2046-956-A SERVICE, OPTICAL DEVICE (7G)
405 1-912-718-11 FLEXIBLE FLAT CABLE (5 CORE)
406 1-912-716-11 FLEXIBLE FLAT CABLE (24 CORE)
ns not supplied
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ns
ns
MS-476 board
(ns)
401 (including MS-476 board)
402
403
403
403
404
406
405
ns
ns
ns
ns
ns
