Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
56
MHC-V21/V21D
Ver. 1.1
0 A-2196-509-A PANEL BOARD, COMPLETE
**********************
< CONNECTOR >
CN4000 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D4000 6-504-215-11 DI HL-364V620MZ-JS
D4001 6-504-213-11 DI HL-364B460MZ-JS
D4002 6-503-605-01 DI UDZVTE-172.0B
< ROTARY ENCODER >
EN4000 1-493-008-11 ENCODER, ROTARY (VOLUME/DJ CONTROL)
< JUMPER RESISTOR >
JR4000 1-216-864-91 SHORT CHIP 0
JR4001 1-216-296-11 SHORT CHIP 0
JR4002 1-216-296-11 SHORT CHIP 0
JR4017 1-216-296-11 SHORT CHIP 0
JR4018 1-216-296-11 SHORT CHIP 0
JR4019 1-216-296-11 SHORT CHIP 0
JR4020 1-216-296-11 SHORT CHIP 0
JR4021 1-216-296-11 SHORT CHIP 0
JR4023 1-216-296-11 SHORT CHIP 0
JR4024 1-216-296-11 SHORT CHIP 0
JR4025 1-216-296-11 SHORT CHIP 0
JR4026 1-216-296-11 SHORT CHIP 0
JR4028 1-216-864-91 SHORT CHIP 0
JR4033 1-216-296-11 SHORT CHIP 0
JR4034 1-216-296-11 SHORT CHIP 0
JR4035 1-216-296-11 SHORT CHIP 0
JR4050 1-216-296-11 SHORT CHIP 0
JR4051 1-216-296-11 SHORT CHIP 0
JR4052 1-216-296-11 SHORT CHIP 0
JR4054 1-216-296-11 SHORT CHIP 0
JR4055 1-216-296-11 SHORT CHIP 0
JR4056 1-216-296-11 SHORT CHIP 0
JR4057 1-216-296-11 SHORT CHIP 0
JR4058 1-216-296-11 SHORT CHIP 0
JR4059 1-216-296-11 SHORT CHIP 0
JR4060 1-216-296-11 SHORT CHIP 0
JR4061 1-216-296-11 SHORT CHIP 0
JR4062 1-216-296-11 SHORT CHIP 0
JR4063 1-216-296-11 SHORT CHIP 0
JR4064 1-216-296-11 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
ND4000 1-483-549-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q4000 6-552-941-01 TR DTC023JUBTL
Q4001 6-552-941-01 TR DTC023JUBTL
Q4002 6-553-756-01 TR NSS40200LT1G
Q4003 6-552-936-01 TR DTC014EUBTL
< SWITCH >
S4000 1-762-875-21 SWITCH, TACTILE (1)
S4001 1-762-875-21 SWITCH, TACTILE (Z)
S4002 1-762-875-21 SWITCH, TACTILE (
+)
S4003 1-762-875-21 SWITCH, TACTILE (
―)
S4004 1-762-875-21 SWITCH, TACTILE (
TUNING ― .)
S4005 1-762-875-21 SWITCH, TACTILE (
TUNING + >)
S4006 1-762-875-21 SWITCH, TACTILE (MIC/GUITAR LEVEL +)
S4007 1-762-875-21 SWITCH, TACTILE (MIC/GUITAR LEVEL ―)
S4008 1-762-875-21 SWITCH, TACTILE (GUITAR)
S4009 1-762-875-21 SWITCH, TACTILE (MIC ECHO)
S4010 1-762-875-21 SWITCH, TACTILE (DJ EFFECT DJ OFF)
S4011 1-762-875-21 SWITCH, TACTILE (DJ EFFECT
SAMPLER
)
S4012 1-762-875-21 SWITCH, TACTILE (N)
S4013 1-762-875-21 SWITCH, TACTILE (x)
S4014 1-762-875-21 SWITCH, TACTILE (BLUETOOTH
PAIRING)
S4015 1-762-875-21 SWITCH, TACTILE (FUNCTION)
S4016 1-762-875-21 SWITCH, TACTILE (W.PARTY CHAIN)
S4017 1-762-875-21 SWITCH, TACTILE
(MEGA BASS
PARTY CHAIN)
S4018 1-762-875-21 SWITCH, TACTILE
(VOICE CHANGER VOCAL FADER)
S4019 1-762-875-21 SWITCH, TACTILE (SPEAKER LIGHT)
S4020 1-762-875-21 SWITCH, TACTILE (DJ EFFECT FLANGER)
S4021 1-762-875-21 SWITCH, TACTILE (DJ EFFECT ISOLATOR)
*************************************************************
0 A-2203-526-A SMPS BOARD, COMPLETE
*********************
*************************************************************
A-2196-512-A SPK LED BOARD, COMPLETE
***********************
< DIODE >
D4300 6-504-214-21 DI HL-3TMH234WW-3.7-HK-BF-SN-J
*************************************************************
MISCELLANEOUS
**************
302 1-912-719-11 FLEXIBLE FLAT CABLE (15 CORE)
304 1-912-625-11 FLEXIBLE FLAT CABLE (7 CORE)
307 1-912-717-11 FLEXIBLE FLAT CABLE (6 CORE)
401 A-1896-391-B LOADING COMPLETE ASSY (T)
(including MS-476 board)
0 404 A-2046-956-A SERVICE, OPTICAL DEVICE (7G)
405 1-912-718-11 FLEXIBLE FLAT CABLE (5 CORE)
406 1-912-716-11 FLEXIBLE FLAT CABLE (24 CORE)
SP1 1-859-268-11 LOUDSPEAKER (6.6CM) (Tweeter) (L-CH)
SP2 1-859-268-11 LOUDSPEAKER (6.6CM) (Tweeter) (R-CH)
SP3 1-859-294-12 LOUDSPEAKER (20CM) (Woofer)
*************************************************************
Note: If fl exible fl at cable is replaced, install it after bending it in
the same form as that before replacement.
SMPS SPK LED
PANEL
SYSSET
