Turning Power On/Off
Preparation
Turning Power On/Off
After connecting the system, turn on the power using the
following procedure.
1
Set the POWER A and B switches of the switcher
processor to ON (“?” side).
When the switcher processor is turned on, the status
indicators for supplies A and B light green.
2
Check that the status indicators on the control panel
are lit green, then press the POWER switch.
The POWER switch mark “1” lights green.
The control panel boots in approximately one minute,
and the top menu list appears on the menu panel
screen.
MVS-6520/6530
Switcher Processor
1
2
3
3
ICP-6520 Control Panel
ICP-6530 Control Panel
