18
3 two claws
4 loading panel
2
1
LOADING PANEL
CASE
Note: Follow the disassembly procedure in the numerical order given.
1 two screws
(case3 TP2)
1 two screws
(case3 TP2)
1 two screws
(case3 TP2)
2 case
