Sony MXD-D4 - Board and Holder Removal; BD (MD) Board and Holder Assembly Removal

20
BD (MD) BOARD
HOLDER ASS’Y
2 holder ass’y
1 claw
5 Remove the solder (four portions).
4 Remove the solder (five portions).
6 two screws (BTP2 × 6)
8 flexible board (CN104)
3 connector
(CN104)
7 BD (MD) board
1 wire (flat type) (17 core)
2 wire (flat type)
(27 core)
