1 MENU t [Brightness/Color] t [White Balance] t desired mode.
2 As necessary, OPTION t adjust the color temperature by pressing the
top/bottom/right/left parts of the control wheel.
Or touch the graph on the screen to adjust the color temperature (NEX-
5R only).
You can adjust the color temperature towards G (green), M (magenta), A (amber) or B (blue).
1 MENU t [Brightness/Color] t [White Balance] t [C.Temp./Filter].
2 OPTION t select the desired color temperature by turning the control
wheel or by touching the desired item on the screen (NEX-5R only).
The higher the number, the more reddish the image, and the lower the number, the more
bluish the image.
3 Adjust the color temperature by pressing the top/bottom/right/left parts of
the control wheel or by touching the graph on the screen (NEX-5R only).
Adjusting the color temperature finely
C.Temp./Filter
z Effects of lighting conditions
The apparent color of the subject is affected by the lighting conditions.
The color temperature is adjusted automatically, but you can adjust color temperature
manually using the [White Balance] function.
Weather/
lighting
Daylight Cloudy Fluorescent Incandescent
Characteristics
of light
White
(standard)
Bluish Green-tinged Reddish
Continued r

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
