The soft keys have different roles, depending on the context.
The assigned role (function) of each soft key is shown on the screen.
To use the function shown at the upper right corner of the screen, press soft key A. To
use the function shown at the lower right corner of the screen, press soft key B. To use
the function shown at the center, press the center of the control wheel (soft key C).
You can assign the functions to the soft key B (page 163).
In this handbook, the soft keys are indicated by the icon or the function shown on the
screen.
You can operate the camera intuitively by touching the screen or sliding your finger
across the screen. Touch the item on the screen to select it. Slide your finger across the
screen to scroll down to hidden items.
Soft keys
Touch panel (NEX-5R only)
In this case, soft key A works as
the MENU (Menu) button, and soft
key B as (View on Smartphone)
button.
A
B
C
Touch the item to select it.
Sliding your finger across the screen scrolls the items. Items on
the screen are replaced with items that were out of view.
Continued r

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
