Sony NEX-5T User Manual

203
GB
Table of
contents
Sample photo Menu Index
Connecting with other equipment
Viewing images on a TV
To view images on the camera using a TV, an HDMI cable (sold separately) and an HD
TV equipped with an HDMI connector are required. Refer also to the operating
instructions supplied with the TV.
1 Turn off both your camera and the TV.
2 Connect the camera to the TV with an HDMI cable (sold separately).
3 Turn on the TV and switch the input.
4 Turn on the camera, and then press the (Playback) button to select
playback mode.
Images shot with the camera appear on the TV screen. Select the desired image with the
control wheel.
• Some devices may not work properly.
• Sounds are output only while recording or playing back movies, when the camera is connected with an
HDMI cable.
• Use an HDMI cable with the HDMI logo.
• Use an HDMI mini connector on one end (for the camera), and a plug suitable for connecting your TV on
the other end.
• Do not connect the camera and equipment to be connected using output terminals. This may cause a
malfunction.
• The peaking function is not enabled when the camera is connected using an HDMI cable.
Notes
1 To the HDMI
connector
2 To the HDMI terminal
HDMI cable
HDMI cable
NEX-6: NEX-5R:
1 To the HDMI
connector
2 To the HDMI terminal
Continued r

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
