Sony NEX-5T User Manual

212
GB
Table of
contents
Sample photo Menu Index
1 Connect the camera to your Mac computer first. Double-click the newly
recognized icon on the desktop t the folder where the images you want
to import are stored.
2 Drag and drop the image files to the hard disk icon.
The image files are copied to the hard disk.
3 Double-click the hard disk icon t the desired image file in the folder
containing the copied files.
The image is displayed.
Complete steps 1 and 2 below before performing the following operations:
• Disconnecting the USB cable.
• Removing the memory card.
• Turning off the camera.
• Drag and drop the icon of the memory card or the drive icon to the “Trash” icon beforehand when you use
a Mac computer, and the camera is disconnected from the computer.
• With Windows 7, the disconnect icon may not be displayed. In such cases, you can disconnect without
following the above procedure.
• Do not disconnect the USB cable when the access lamp is lit. The data may be damaged.
Importing images to the computer (Mac)
Disconnecting the camera from the computer
1 Double-click the disconnect icon on the task
bar.
• For Windows 7, click , and then click .
2 Click (Safely remove USB Mass Storage
Device).
Disconnect icon
Notes
z The software for Mac computers
For details on other software for Mac computers, access the following URL:
http://www.sony.co.jp/imsoft/Mac/
Windows Vista

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
