Sony NEX-5T User Manual

131
GB
Table of
contents
Sample photo Menu Index
Phase Detection AF Area
Sets whether or not to display the Phase Detection AF ranging points on the screen.
1 MENU t [Setup] t [Phase Detection AF Area] t desired mode.
• When the aperture value is greater than F6.3, Phase Detection AF is unavailable. You can only use
Contrast AF.
• Phase Detection AF is available only with compatible lenses. If an incompatible lens is attached, you will
be unable to use Phase Detection AF. Phase Detection AF may not operate even with some compatible
lens, such as lenses purchased in the past that have not been updated. For details on compatible lenses,
visit the Sony web site in your area, or consult your Sony dealer or local authorized Sony service facility.
• When using an A-mount lens (sold separately) with the Mount Adaptor (sold separately), Phase
Detection AF of the camera will not be activated.
• Phase Detection AF is unavailable for movie shooting. The Phase Detection AF ranging points are not
displayed on the screen.
On The Phase Detection AF ranging points
are displayed.
Off The Phase Detection AF ranging points are not displayed.
Notes
Phase Detection AF
ranging points

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
