Sony NEX-5T User Manual

239
GB
Table of
contents
Sample photo Menu Index
The available [Autofocus Area] settings differ depending on the Mount Adaptor type.
• You may not be able to use the Mount Adaptor with certain lenses. Consult your Sony dealer or local
authorized Sony service facility on compatible lenses.
• When you are using the Mount Adaptor and record movies, press the shutter button halfway down to use
autofocus.
• You cannot use the AF illuminator when using an A-mount lens.
• The sound of the lens and the camera in operation may be recorded during movie recording. You can turn
the sound off by selecting MENU t [Setup] t [Movie Audio Rec] t [Off].
• It may take a long time or may be difficult for the camera to focus, depending on the lens used or the
subject.
• The light of the flash may be blocked by the lens attached.
LA-EA1
(Multi) The camera determines which of the 25 AF areas is used for
focusing.
(Center) The camera uses the AF area located in the center area
exclusively.
(Flexible Spot) Moves the focusing area to focus on a small subject or narrow
area by pressing the top/bottom/right/left of the control wheel.
LA-EA2
(Wide) The camera determines which of the 15 AF areas is used for
focusing.
(Spot) The camera uses the AF area located in the center area
exclusively.
(Local) Choose the area for which you want to activate the focus from
among 15 AF areas with the control wheel.
Notes

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
