Sony NEX-5T User Manual

ii
GB
About the
NEX-5T
Index
(NEX-5T)
Renamed functions on the
NEX-5T
On the NEX-5T, the following functions have been renamed from the NEX-5R, but the
features are the same.
To search for these functions in this handbook, use the NEX-5R function names.
One-touch sharing (Sending an
image to a Smartphone)
With just one touch, you can connect the camera and an NFC-enabled Android
Smartphone, and send an image displayed on the camera screen directly to the
Smartphone.
Download and install the application “PlayMemories Mobile” from your Smartphone’s
application store.
If “PlayMemories Mobile” is already installed on your Smartphone, be sure to update it
to the latest version.
For details on “PlayMemories Mobile,” refer to the support page (http://www.sony.net/
pmm/).
To send images to an iPhone, or to an Android Smartphone without the NFC function,
refer to “Sending images without using the NFC function”.
NEX-5R function name NEX-5T function name
Object Tracking Tracking Focus
Reset View on Smartphone SSID/PW Reset
View on Smartphone Send to Smartphone
1 Play back a single image to be sent on the
camera.
2 Activate the NFC function of the Smartphone.
• Refer to the instruction manual of the Smartphone on how to activate the NFC function.
Continued r

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
