Sony NEX-5T User Manual

17
GB
Table of
contents
Sample photo Menu Index
A Screw
B Flash
1)
C Connector
1)
1)
Do not touch this part directly.
If it is dirty, wipe it off with a soft clean cloth.
E PZ 16 – 50 mm F3.5–5.6 OSS (supplied with NEX-6L/6Y/5RL/5RY)
A Zooming/Focusing ring
B Zooming lever
C Mounting index
D Lens contacts
1)
1)
Do not touch this part directly.
Flash HVL-F7S (NEX-5R only)
Lens
z Using the Zooming/Focusing ring
When an E PZ 16 – 50 mm F3.5–5.6 OSS lens is attached, functions assigned to the
Zooming/Focusing ring change according to the [AF/MF Select] settings (page 79).
AF/MF Select Function assigned to the Zooming/Focusing ring
(Autofocus) Zoom
(DMF (Direct
manual focus))
Before pressing the shutter button halfway down: Zoom
While pressing the shutter button halfway down: Focus
(Manual Focus) Focus
Continued r

Sony NEX-5T Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (23.5 x 15.6 mm)
Effective Pixels	16.1 MP
ISO Range	100-25600
Autofocus Points	25
Lens Mount	Sony E-mount
Image Processor	BIONZ
Screen Size	3.0"
Screen Resolution	921, 600 dots
Video Resolution	1920 x 1080
Video Frame Rate	60p, 60i, 24p
Maximum Shutter Speed	1/4000 sec
Minimum Shutter Speed	30 sec
Continuous Shooting	10 fps
Built-in Flash	No
External Flash	Yes (via hot shoe)
Wireless Connectivity	Wi-Fi, NFC
Battery	NP-FW50
Battery Life	330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Weight	276 g (with battery and memory card)
