6-10
5. Auto Adjustment
Auto Adjustment
1. Auto TRK. Offset
2. Auto Focus Balance
3. Auto Focus Offset
4. Auto Focus Gain
5. Auto TRK. Gain
6. Auto EQ
7. Auto L.F. Offset
8. Auto Group Delay
SA. 04EF905 SI. 00 EMG. 00
DVD SL 12 cm Jitter FF
On this screen, each item can be adjusted automatically. Select
the desired number 1 to 8 from the remote commander, and
selected item is adjusted automatically.
1 Auto TRK. Offset: Adjusts tracking offset.
2 Auto Focus Balance: Adjusts focus balance.
3 Auto Focus Offset: Adjusts focus offset.
4 Auto Focus Gain: Adjusts focus gain.
5 Auto TRK. Gain: Adjusts track gain.
6 Auto EQ:
7 Auto L.F. Offset: Adjusts loop filter offset.
8 Auto Group Delay:
6. Memory Check
The display image is shown below and three screens in total can
be selected.
EEPROM DATA 1 -– DL -–
CD LCD SL L0 L1
Focus Gain xx xx xx xx xx
TRK. Gain xx xx xx xx xx
FCS Balnce xx xx xx xx xx
Focus Bias xx xx xx xx xx
TRV Offset xx xx xx xx xx
L.F. Offset xx xx xx xx xx
EQ. Boost xx xx xx xx xx
_
UP : Last Data
DOWN : Next Data
CLEAR : Default Set page.1/3
EEPROM DATA 2 -– DL -–
CD LCD SL L0 L1
RF Jitter xx -- xx xx xx
RF Level xx -- xx -- --
FE Level xx -- xx -- --
FE Balance xx -- xx -- --
TRV.Level xx -- xx -- --
TE Gain xx xx -- -- --
PI Level xx -- xx xx --
_
UP : PREV Data
DOWN : Next Data
CLEAR : Default Set page.2/3
EEPROM DATA 3 -– DL -–
CD LCD SL L0 L1
Analog FRSW xx xx xx xx xx
PLL Dac Gain xx xx xx xx xx
Mirror Time xx xx xx xx xx
_ THR A&L xx xx xx/xx xx xx
UP : PREV Data
DOWN : First Data
CLEAR : Default Set page.3/3
On this screen, current servo adjusted data stored in the
EEPROM are displayed. The adjusted data are initialized by
pressing the [CLEAR] key, but be careful that they are not
recoverable after initialization.
Before clearing the adjusted data, make a note of the set data.
This screen will also appear if - All is selected in the Drive
Auto Adjustment. In this case, default setting cannot be made.
Data of “THR A & L” data on the second page cannot be change
if default setting is once made.
To Next Page
