Sony RMT-D152A - Board Differential Part List

DVP-NS325/NS330/NS333/NS430/NS433/NS530/NS725P/NS730P
4-17 4-18
NS325 NS330/NS333 NS430/NS433 NS530 NS725P NS730P
C212 xx 1u 1u xx xx xx
50V 50V
C215 xx 220p 220p 220p xx 220p
50V 50V 50V 50V
CH CH CH CH
C216 xx 220p 220p 220p xx 220p
50V 50V 50V 50V
CH CH CH CH
C227 xx xx 47u 47u 47u 47u
16V 16V 16V 16V
D203 xx DAP202K-T- DAP202K-T- xx xx xx
IC204 xx xx GP1FA55OTZ GP1FA55OTZ GP1FA55OTZ GP1FA55OTZ
Q206 xx MUN2213T1 MUN2213T1 xx xx xx
Q209 xx UN2217-TX UN2217-TX xx xx xx
Q210 xx MSB709-RT1 MSB709-RT1 xx xx xx
R214 xx 4700 4700 xx xx xx
R231 xx 10k 10k xx xx xx
R232 xx 10k 10k xx xx xx
R233 xx 47k 47k xx xx xx
R235 4700 xx xx 4700 4700 4700
R236 xx 10k 10k xx xx xx
R237 xx 4700 4700 xx xx xx
R239 xx 100k 100k xx xx xx
R242 xx xx xx xx xx xx
R243 xx xx xx xx xx xx
[AUDIO]
NS325/NS330/ NS725P/NS730
NS333/NS430/
NS433/NS530
CN402 7p 7p
CN406 xx xx
D401 xx EB3804X-TP
R436 xx 10k
R437 10k xx
R461 xx 220
[IF]
AF-98 Board Differential Part List
[VIDEO]
NS325/NS530 NS330/NS333/ NS730P/
NS430/NS433 NS725P
C112 0.1u xx 0.1u
16V 16V
BB
CN102 xx 21P xx
D108 HZM6.8WA1 xx HZM6.8WA1
D109 HZM6.8WA1 xx HZM6.8WA1
IC102 LA73050-TL LA73051-TL LA73053-TL
J102 3P xx 3P
J103 xx xx xx
Q104 MUN2213T1 xx MUN2213T1
Q105 MUN2111T1 xx MUN2111T1
Q106 xx 2SA1162-YG xx
R121 10K xx 3300
R122 xx 1K xx
R127 68 xx 68
R128 68 xx 68
R129 10K xx 10K
R133 68 xx 68
