Sony RMT-D152A - Waveforms

DVP-NS325/NS330/NS333/NS430/NS433/NS530/NS725P/NS730P
4-5 4-6
AF-098 BOARD MB-108 BOARD
IC102 ed
1
2.5Vp-p
H
IC102 ea
2
2.0Vp-p
H
IC102 wl
3
2.0Vp-p
H
IC102 wf
4
2.0Vp-p
H
IC102 ws
5
1.4Vp-p
H
IC102 w;
6
1.4Vp-p
H
IC404 3
7
3.9Vp-p
125nsec
IC103 3
1
3.3Vp-p
1.17msec
IC103 8
2
3.3Vp-p
38nsec
IC103 9 q;
3
3.3Vp-p
42nsec
IC103 qg
4
IC104 tf
5
3.3Vp-p
60nsec
IC201 2 (CD PB)
6
20nsec
IC201 2 (DVD PLAY)
6
0.79Vp-p
20nsec
IC201 ra (CD PB)
7
1.6Vp-p
IC201 ra (DVD PLAY)
7
1.7Vp-p
IC201 rs (CD PB)
8
383mVp-p
IC201 rs (DVD PLAY)
8
433mVp-p
IC201 tl
9
1.3Vp-p
890nsec
IC301 (DVD PLAY)
10
1.34Vp-p
40ns/div
IC301 (CD PB)
11
1.46Vp-p
0.2us/div
IC301 (CD PB)
12
1.5Vp-p
1.8msec
IC301 (DVD PLAY)
12
1.62Vp-p
1.0msec
IC301 (CD PB)
13
770mVp-p
21msec
IC301 (DVD PLAY)
13
466mVp-p
32.4msec
IC301
14
1.1Vp-p
30nsec
IC403 ws
15
3.3Vp-p
40nsec
IC403 tg
16
1.0Vp-p
63.5usec
IC403 tj
17
979mVp-p
63.5usec
IC403 tl
18
675mVp-p
63.5usec
IC403 ya
19
666mVp-p
6.35usec
IC403 yd
20
625mVp-p
6.8usec
IC403 yg
21
1.1Vp-p
33.5usec
IC403
22
3.3Vp-p
38nsec
IC502 r;
23
3.3Vp-p
36nsec
IC502
24
3.3Vp-p
18.3nsec
IC504 es
25
3.3Vp-p
36nsec
IC504 ej
26
483mVp-p
63.5nsec
IC504 ek
27
633mVp-p
63.5usec
IC504 el
28
131Vp-p
63.5usec
IC504 rs
29
508Vp-p
280nsec
IC504 rd
30
979mVp-p
63.5usec
IC504 rf
31
1.08Vp-p
63.4usec
IC601 1
32
3.3Vp-p
42nsec
3.3Vp-p
30nsec
0.47Vp-p
111
125
125
150 158
103
160
113
124
124
WAVEFORMS
AF-098/MB-108
