8-6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
<CONNECTOR>
CN102 1-815-149-11 CONNECTOR, FPC/FFC(1MM PIC)21P
(NS330/NS333/NS430/NS433)
CN203 1-816-367-31 CONNECTOR, BOARD TO BOARD 25P
CN400 1-961-633-11 MF-128
CN401 1-816-365-21 CONNECTOR, BOARD TO BOARD 9P
CN402 1-815-382-11 CONNECTOR, FPC/FFC 7P
CN405 1-785-530-11 PIN, CONNECTOR (PC BOARD) 10P
(NS325/NS530/NS725P/NS730P)
CN471 1-564-683-11 PIN, CONNECTOR 13P
CN471 1-573-911-11 PIN, CONNECTOR 13P
<DIODE>
D108 8-719-067-40 DIODE STZ6.8N-T146
(NS325/NS530/NS725P/NS730P)
D109 8-719-067-40 DIODE STZ6.8N-T146
(NS325/NS530/NS725P/NS730P)
D201 8-719-050-38 DIODE M1MA152WK-T1
D201 8-719-914-43 DIODE DAN202K-T-146
D202 8-719-050-37 DIODE M1MA152WA-T1
D203 8-719-914-45 DIODE DAP202K-T-146
(NS330/NS333/NS430/NS433)
D204 8-719-404-50 DIODE MA111-TX
D204 8-719-988-61 DIODE 1SS355TE-17
D401 6-500-564-01 DIODE UB3803X-J582K (NS725P/NS730P)
<FERRITE BEAD>
FB471 1-216-295-00 SHORT CHIP 0
<IC>
IC102 8-759-826-45 IC LA73050-TLM (NS325/NS530)
IC102 8-759-826-46 IC LA73051-TLM
(NS330/NS333/NS430/NS433)
ET471 1-537-738-21 TERMINAL, EARTH
ET472 1-537-738-21 TERMINAL, EARTH
IC102 6-701-820-01 IC LA73053-TLM-E (NS725P/NS730P)
IC103 8-759-662-86 IC NJM79M05DL1A(TE2)
IC103 8-759-667-17 IC L79M05TLL-SONY-TL
IC201 6-701-937-01 IC TJM4558CDT
IC201 8-759-249-16 IC NJM4558M-TE2
IC201 8-759-425-23 IC BA4558F-E2
IC203 8-759-711-59 IC NJM78L05UA-TE1
IC204 8-749-017-31 IC GP1FA550TZ
(NS530/NS430/NS433/NS725P/NS730P)
IC404 6-802-768-01 IC 86CK74AFG-4H19(M)
IC407 6-703-743-01 IC AN13992A
IC408 6-703-742-01 IC S-80830CNUA-B8P-T2
(NS325/NS530/NS725P/NS730P)
IC473 6-701-875-01 IC LMS8117ADTX-1.8/NOPB
IC474 8-759-666-12 IC MM1385DNLE
<JACK>
J102 1-793-445-11 JACK, PIN 3P
(NS325/NS530/NS725P/NS730P)
J103 1-794-198-11 CONNECTOR, S TERMINAL
(NS325/NS530/NS725P/NS730P)
J104 1-815-358-11 JACK, PIN (3P)
J201 1-793-446-21 JACK, PIN 1P
<JUMPER RESISTOR>
JR101 1-216-295-00 SHORT CHIP 0
JR102 1-216-295-00 SHORT CHIP 0
JR103 1-216-295-00 SHORT CHIP 0
JR104 1-216-295-00 SHORT CHIP 0
JR107 1-216-295-00 SHORT CHIP 0
JR108 1-216-295-00 SHORT CHIP 0
JR109 1-216-295-00 SHORT CHIP 0
JR110 1-216-295-00 SHORT CHIP 0
JR111 1-216-295-00 SHORT CHIP 0
JR112 1-216-295-00 SHORT CHIP 0
JR113 1-216-295-00 SHORT CHIP 0
JR114 1-216-295-00 SHORT CHIP 0
JR115 1-216-295-00 SHORT CHIP 0
JR202 1-216-295-00 SHORT CHIP 0
JR203 1-216-295-00 SHORT CHIP 0
JR204 1-216-295-00 SHORT CHIP 0
JR205 1-216-295-00 SHORT CHIP 0
JR206 1-216-295-00 SHORT CHIP 0
JR208 1-216-295-00 SHORT CHIP 0
JR209 1-216-295-00 SHORT CHIP 0
JR210 1-216-295-00 SHORT CHIP 0
JR211 1-216-295-00 SHORT CHIP 0
JR212 1-216-295-00 SHORT CHIP 0
JR214 1-216-295-00 SHORT CHIP 0
JR215 1-216-295-00 SHORT CHIP 0
JR401 1-216-295-00 SHORT CHIP 0
JR403 1-216-295-00 SHORT CHIP 0
JR404 1-216-295-00 SHORT CHIP 0
JR405 1-216-295-00 SHORT CHIP 0
JR406 1-216-295-00 SHORT CHIP 0
JR407 1-216-295-00 SHORT CHIP 0
JR408 1-216-295-00 SHORT CHIP 0
JR409 1-216-295-00 SHORT CHIP 0
JR410 1-216-295-00 SHORT CHIP 0
JR411 1-216-295-00 SHORT CHIP 0
JR413 1-216-295-00 SHORT CHIP 0
JR415 1-216-295-00 SHORT CHIP 0
JR417 1-216-295-00 SHORT CHIP 0
JR418 1-216-295-00 SHORT CHIP 0
JR419 1-216-295-00 SHORT CHIP 0
JR420 1-216-295-00 SHORT CHIP 0
JR421 1-216-295-00 SHORT CHIP 0
JR422 1-216-295-00 SHORT CHIP 0
JR423 1-216-295-00 SHORT CHIP 0
JR424 1-216-295-00 SHORT CHIP 0
JR425 1-216-295-00 SHORT CHIP 0
<FLUORESCENT INDICATOR>
ND401 1-518-876-11 VACUUM FLUORESCENT DISPLAY
<IC LINK>
PS471 1-576-508-21 IC LINK 0.7A 50V
PS472 1-576-508-21 IC LINK 0.7A 50V
AF-98
