Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R406 1-218-831-11 METAL CHIP 220 0.5% 1/10W
(Except: NS725P/NS730P)
R407 1-218-831-11 METAL CHIP 220 0.5% 1/10W
(Except: NS725P/NS730P)
R408 1-218-831-11 METAL CHIP 220 0.5% 1/10W
(Except: NS725P/NS730P)
R409 1-218-831-11 METAL CHIP 220 0.5% 1/10W
(Except: NS725P/NS730P)
R410 1-218-831-11 METAL CHIP 220 0.5% 1/10W
(Except: NS725P/NS730P)
R411 1-218-831-11 METAL CHIP 220 0.5% 1/10W
(Except: NS725P/NS730P)
R412 1-216-833-11 METAL CHIP 10K 5% 1/10W
R413 1-216-831-11 METAL CHIP 6.8K 5% 1/10W
R414 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R426 1-216-833-11 METAL CHIP 10K 5% 1/10W
R430 1-216-797-11 METAL CHIP 10 5% 1/10W
R439 1-216-864-11 SHORT CHIP 0
R507 1-216-809-11 METAL CHIP 100 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R436 1-216-864-11 SHORT CHIP 0
R512 1-216-864-11 SHORT CHIP 0
(NS725P/NS730P)
R513 1-218-285-11 METAL CHIP 75 5% 1/10W
(NS725P/NS730P)
R514 1-218-292-11 METAL CHIP 20K 5% 1/10W
(NS725P/NS730P)
R536 1-216-809-11 METAL CHIP 100 5% 1/10W
(NS725P/NS730P)
R558 1-216-809-11 METAL CHIP 100 5% 1/10W
(NS725P/NS730P)
R438 1-216-864-11 SHORT CHIP 0
(NS725P/NS730P)
R559 1-216-809-11 METAL CHIP 100 5% 1/10W
(NS725P/NS730P)
R568 1-216-819-11 METAL CHIP 680 5% 1/10W
(Except: NS725P/NS730P)
R570 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(Except: NS725P/NS730P)
R571 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(Except: NS725P/NS730P)
R573 1-216-809-11 METAL CHIP 100 5% 1/10W
(Except: NS725P/NS730P)
R574 1-218-834-11 METAL CHIP 300 0.5% 1/10W
(Except: NS725P/NS730P)
R575 1-218-834-11 METAL CHIP 300 0.5% 1/10W
(Except: NS725P/NS730P)
R576 1-218-834-11 METAL CHIP 300 0.5% 1/10W
(Except: NS725P/NS730P)
R577 1-218-834-11 METAL CHIP 300 0.5% 1/10W
(Except: NS725P/NS730P)
R578 1-218-834-11 METAL CHIP 300 0.5% 1/10W
(Except: NS725P/NS730P)
R579 1-218-834-11 METAL CHIP 300 0.5% 1/10W
(Except: NS725P/NS730P)
R585 1-216-833-11 METAL CHIP 10K 5% 1/10W
(Except: NS725P/NS730P)
R601 1-216-809-11 METAL CHIP 100 5% 1/10W
R613 1-216-864-11 SHORT CHIP 0
(Except: NS725P/NS730P)
R614 1-216-864-11 SHORT CHIP 0
(Except: NS725P/NS730P)
R607 1-216-864-11 SHORT CHIP 0
(Except: NS725P/NS730P)
R608 1-216-864-11 SHORT CHIP 0
(Except: NS725P/NS730P)
R609 1-216-864-11 SHORT CHIP 0
(Except: NS725P/NS730P)
R612 1-216-864-11 SHORT CHIP 0
(Except: NS725P/NS730P)
<COMPOSITION CIRCUIT BLOCK>
RB102 1-233-270-11 NETWORK, RES (8 GANG) 10K
<VARIABLE RESISTOR>
RV401 1-223-583-41 RES, ADJ, CARBON (3 TYPE) 1K
(Except: NS725P/NS730P)
RV501 1-223-583-41 RES, ADJ, CARBON (3 TYPE) 1K
(Except: NS725P/NS730P)
RV502 1-223-583-41 RES, ADJ, CARBON (3 TYPE) 1K
(Except: NS725P/NS730P)
<COMPOSITION CIRCUIT BLOCK>
RB102 1-233-270-11 NETWORK, RES (8 GANG) 10K
<VIBRATOR>
X101 1-795-174-11 VIBRATOR, CERAMIC
X102 1-795-630-11 VIBRATOR, CRYSTAL (NS325/NS530)
* A-6061-358-A SW-384 BOARD COMPLETE
(NS325:US,CND,PX,E,MX/NS530)
*********************************
* A-6061-937-A SW-384 BOARD COMPLETE
(NS325:BR,AR)
*********************************
* A-6061-513-A SW-384 BOARD COMPLETE
(NS330/NS333)
*********************************
* A-6061-546-A SW-384 BOARD COMPLETE
(NS430/NS433)
*********************************
* A-6061-689-A SW-384 BOARD COMPLETE
(NS725P/NS730P: HK,KR,SP,ME2,AUS)
*********************************
<CAPACITOR>
C820 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
<CONNECTOR>
CN801 1-815-569-11 CONNECTOR, FFC/FPC 7P
<IC>
IC820 6-703-744-01 IC GP1UE26SXKOF
<JUMPER RESISTOR>
JR801 1-216-295-91 SHORT CHIP 0
JR802 1-216-295-91 SHORT CHIP 0
MB-108 SW-384
