5-4
DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
Pin No. Pin name Type Function
157 XMUTE123 Output, PD, SMT Motor drive channel 1,2 & 3 mute
158 XMUTE4 Output, PD, SMT Servo Driver MUTE Signal
159 DDC_SDA Output, PD, SMT DDC IIC Data (For HDMI)
160 DVDD18 1.8V power pin for internal digital circuitry
161 DDC_SCL Output, PD, SMT DDC IIC Clock (For HDMI)
162 HTPLG Input, PD, SMT Hot Plug Detection (For HDMI)
163 AGND33_VPLL Ground Ground pin for HDMI TX
164 EXT_RES Analog Input External resistor for HDMI TX
165 AVDD33_VPLL Power 3.3V power pin for HDMI TX
166 AVDD33_TX Power 3.3V power pin for HDMI TX
167 EXT_CAP Analog Input External capacitor for HDMI TX
168 AGND33_TX Ground Ground pin for HDMI TX
169 AGND18_TX2 Ground Ground pin for HDMI TX
170 TXCN Analog Output Negative TX Clock
171 TXCP Analog Output Positive TX Clock
172 AVDD18_TX1 Power 1.8V power pin for HDMI TX
173 TX0N Analog Output Negative TX CH0
174 TX0P Analog Output Positive TX CH0
175 AGND18_TX1 Ground Ground pin for HDMI TX
176 TX1N Analog Output Negative TX CH1
177 TX1P Analog Output Positive TX CH1
178 AVDD18_TX0 Power 1.8V power pin for HDMI TX
179 TX2N Analog Output Negative TX CH2
180 TX2P Analog Output Positive TX CH2
181 AGND18_TX0 Ground Ground pin for HDMI TX
18 2 R/CR/PR Analog Output Red or Cr
18 3 B/CB/PB Analog Output Blue or Cb
184 DACVSSA Ground Ground pin for Video DAC circuitry
185 Y/G Analog Output Green or Y
186 DACVDDA Power 3.3V power for Video DAC circuitry
187 CVBS Analog Output Analog composite output
188 DACVSSB Ground Ground pin for Video DAC circuitry
189 C Analog Output Analog chroma output
190 DACVDDB Power 3.3V power for Video DAC circuitry
191 Y Analog Output Analog Y output
192 DACVSSC Ground Ground pin for Video DAC circuitry
193 FS Analog Input Full Scale Adjustment
194 VREF Analog Input Bandgap Ref Voltage
195 DACVDDC Power 3.3V power for Video DAC circuitry
196 HPD_PON Output, PD, SMT Fixed High
197 NC Not used
198 NC Not used
199 NC Not used
200 NC Not used
201 NC Not used
202 NC Not used
203 NC Not used
204 NC Not used
205 MV-55: NC Not used
MV-56: RGBSEL Output, PD, SMT RGB/YCbCr select output signal (H:RGB Disable, L:RGB Enable)
206 WIDE Output Voltage select output signal for S terminal (H: 16:9, L: 4:3)
207 DVDD33 Power 3.3V power pin for internal digital circuitry
208 NC Not used
To Next Page
