5-5
DVP-NS72HP/NS77H/NS77HP/NS78H/NS78HP
Pin No. Pin name Type Function
209 MV-55: NC Not used
MV-56: EUROVY Output, PD, SMT CVBS/S terminal select output signal (H: CBVS, L: S-terminal)
210 XMAMUTE Output, PD, SMT Main Audio Mute signal (H: Unmute, L: Mute)
211 MV-55: NC Not used
MV-56: DISC/EXT Output, PD, SMT DISC/External input select output signal (H: DISC, L: EXTin)
212 DVDD18 Power 1.8V power pin for internal digital circuitry
213 NC Not used
214 NC Not used
215 SPDIF Output SPDIF output
216 APLLVDD Power 3.3V Power pin for Clock circuitry
217 APLLCAP Input APLL External Capacitance connection
218 APLLVSS Ground Ground pin for Clock circuitry
219 ADACVSS2 Ground Ground pin for Audio DAC circuitry
220 ADACVSS1 Ground Ground pin for Audio DAC circuitry
221 NC Not used
222 NC Not used
223 AR Analog Output Audio DAC Right channel output
224 AVCM Analog Output Audio DAC Reference Voltage
225 AL Analog Output Audio DAC Left Channel Output
226 NC Not used
227 NC Not used
228 ADACVDD2 Power 3.3V Power pin for Audio DAC circuitry
229 ADACVDD1 Power 3.3V Power pin for Audio DAC circuitry
230 NC Not used
231 NC Not used
232 ADACVSS33 Ground Ground pin for Audio DAC circuitry
233 ADACVDD33 Power 3.3V Power pin for Audio DAC circuitry
234 SADCVDD18 Power 1.8V Power pin for SACD ADC
235 SADCVSS18 Ground Ground pin for SACD ADC
236 RFGND18 Ground Ground pin for internal analog circuitry
237 RFVDD18 Power 1.8V power pin for internal analog circuitry
238 XTALO Output 27M crystal output
239 XTALI Input 27M crystal input
240 JITFO Analog Output The output terminal of RF jitter meter
241 JITFN Analog Input The input terminal of RF jitter meter
242 PLLVSS Ground Ground pin for data PLL and related analog circuitry
243 PLLVDD3 Power 3.3V power pin for data PLL and related analog circuitry
244 LPFON Analog Output The negative output of loop filter amplifier
245 LPFIP Analog Input The positive input terminal of loop filter amplifier
246 LPFIN Analog Input The negative input terminal of loop filter amplifier
247 LPFOP Analog Output The positive output of loop filter amplifier
248 ADCVDD3 Power 3.3V Power pin for ADC circuitry
249 ADCVSS Ground Ground pin for ADC circuitry
250 RFVDD3 Power 3.3V power pin for RF digital circuitry
25 1 RFRPDC Analoig Output RF ripple detect output
25 2 RFRPAC Analog Input RF ripple detect input (through AC-coupling)
253 HRFZC Analog Input High frequency RF ripple zero crossing
254 CRTPLP Analog Output Defect level filter capacitor connecting
255 RFGND Ground Ground pin for RF digital circuitry
256 OSP Analog Output RF Offset cancellation capacitor connecting
5-5E
