6 Click [Finish].
Specifications
AUDIO POWER
SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
With 4 ohms loads, driven from 80 - 20 kHz;
rated 6 watts minimum RMS power, with no
more than 1 % total harmonic distortion from
100 milliwatts to rated output.
Power Output (reference):
10 W (4 ohms, 1 kHz, THD 10%)
Wireless LAN section
Compatible standards:
IEEE 802.11 b/g
(WEP 64 bit, WEP 128 bit,
WPA/WPA2-PSK (AES),
WPA/WPA2-PSK (TKIP))
Radio frequency:
2.4 GHz
Inputs/Outputs
Speakers
Approx. 50 mm (2 in) diameter × 1
AUDIO IN jack:
Stereo mini jack
Voltage: 1.0 V
Network port:
10BASE-T/100BASE-TX (Auto Polarity)
General
Power requirements:
AC adaptor
Input: 100-240 V AC, 50/60 Hz
Output: DC 13 V 2 A
