— 21 —
SAT-A55P/B55P
SECTION 5: ELECTRICAL PARTS LIST
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF.NO. PART NO. DESCRIPTION VALUES
The components in this manual identifi ed by the following
symbol: indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation for
each set.
Should replacement be required for one of these
components, replace only with the value originally used.
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specifi e.
When ordering parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION VALUES
A
A
* A-1299-328-A A BOARD, COMPLETE (SAT-A55P ONLY)
* A-1299-327-A A BOARD, COMPLETE (SAT-B55P ONLY)
1-533-223-11 HOLDER, FUSE
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-11 SCREW (M3X10), P, SW (+)
4-382-854-41 SCREW (M3X8), P, SW (+)
CAPACITOR
C010 1-104-665-11 ELECT 100µF 20% 10V
C100 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C101 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C102 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C103 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C104 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C105 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C106 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C107 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C108 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C109 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C110 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C111 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C112 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C113 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C114 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C115 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C116 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C117 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C118 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C119 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C120 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C121 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C122 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C123 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C124 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C125 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C126 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C127 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C128 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C129 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C130 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C131 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C132 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C133 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C134 1-104-665-11 ELECT 100µF 20% 10V
C135 1-131-379-00 TANTALUM 22µF 10% 6.3V
C136 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C137 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C138 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C140 1-104-665-11 ELECT 100µF 20% 10V
C150 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C151 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C152 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C153 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C154 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C156 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C157 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C158 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C159 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C160 1-126-916-11 ELECT 1000µF 20% 6.3V
C161 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C162 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C163 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C164 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C165 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C166 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C167 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C171 1-113-619-11 CERAMIC CHIP 0.47µF 10V
C181 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C192 1-216-864-11 SHORT
C193 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C194 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C195 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C196 1-104-665-11 ELECT 100µF 20% 10V
