Sony SCD-CE595 - IC705 System Controller Pin Functions (Continued)

Sony SCD-CE595
38 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
21
SCD-CE595
Pin No. Pin Name I/O Description
66 FEW I Flash writing Enable
67 MD2 I Muving mode control 2
68 PF7 Not used (open)
69 AS Not used (open)
70 XDR O Reed sycle signal
71 XWR O Write sycle signal
72 XWRST O Waltz reset signal output
73 XWAIT I Bus sycle wait signal input
74 SMUTE O Waltz smute signal output
75 EPR/B I Read/Busy signal input from the EEPROM (IC702)
76 XEPCE O XCS signal output to the EEPROM (IC702)
77 XEWC O XWC signal output to the EEPROM (IC702)
78 P32 O Not used (open)
79 EEPS0 O Communication signal to the EEPROM (IC702)
80 EEPS1 I Communication signal from the EEPROM (IC702)
81 EEPSC O Communication signal to the EEPROM (IC702)
82 P36 Not used (open)
83 IFS0 O Communication signal to the IS CON (IC801)
84 IFS1 I Communication signal from the IS CON (IC801)
85 IFSCK O Communication signal to the IS CON (IC801)
86 P74 Not used (open)
87 XCS O WALTZ chip select
88 P72 Not used (open)
89 P71 Not used (open)
90 P70 Not used (open)
91 XIFINT I ACK input signal from the IS CON (IC801)
92 XINTO I WALTZ input from the Digital Servo Processor (IC706)
93 PG2 Ground terminal
94 MZR I ZEROR input signal from DAC (IC200)
95 MZL I ZEROL input signal from DAC (IC200)
96 XIFCS O Chip select to the IS CON (IC801)
97 R MUTE O Rch mute signal output
98 L MUTE O Lch mute signal output
99 INIT DAC O DAC int output
100 M/2 O Mch mute control output (surr/Cntr/Sw)
