32
SCD-CE595
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-862-176-11 POWER SW BOARD
****************
< CAPACITOR >
0 C891 1-113-920-11 CERAMIC 0.0022uF 20% 250V
< CONNECTOR >
* CN891 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
< SWITCH >
0 S891 1-762-581-11 SWITCH, AC POWER PUSH (1 KEY) (POWER)
************************************************************
1-862-175-11 PT BOARD
*********
< CAPACITOR >
0 C101 1-113-920-11 CERAMIC 0.0022uF 20% 250V
< CONNECTOR >
* CN101 1-568-226-11 PIN, CONNECTOR (3.96mm PITCH) 2P
************************************************************
A-4750-527-A RF BOARD, COMPLETE
*******************
< CAPACITOR >
C001 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C002 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C004 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C005 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C006 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C007 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C008 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C009 1-124-779-00 ELECT CHIP 10uF 20% 16V
C011 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C015 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C016 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C017 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C018 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C019 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C021 1-124-779-00 ELECT CHIP 10uF 20% 16V
C022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C023 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C024 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C027 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C033 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C034 1-164-227-11 CERAMIC CHIP 0.022uF 10% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C038 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C039 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C040 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C043 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C044 1-124-779-00 ELECT CHIP 10uF 20% 16V
C046 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C048 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-879-21 CONNECTOR, FFC (LIF (NON-ZIF)) 31P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D004 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 6-703-445-01 IC SP3726A
< COIL >
L001 1-412-031-11 INDUCTOR 47uH
L002 1-412-031-11 INDUCTOR 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R002 1-216-809-11 METAL CHIP 100 5% 1/10W
R003 1-216-809-11 METAL CHIP 100 5% 1/10W
R004 1-216-864-11 SHORT CHIP 0
R005 1-216-845-11 METAL CHIP 100K 5% 1/10W
R006 1-216-838-11 METAL CHIP 27K 5% 1/10W
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-820-11 METAL CHIP 820 5% 1/10W
R010 1-216-841-11 METAL CHIP 47K 5% 1/10W
R011 1-216-809-11 METAL CHIP 100 5% 1/10W
R013 1-216-833-11 METAL CHIP 10K 5% 1/10W
R018 1-216-833-11 METAL CHIP 10K 5% 1/10W
R020 1-216-803-11 METAL CHIP 33 5% 1/10W
R023 1-216-803-11 METAL CHIP 33 5% 1/10W
R025 1-216-841-11 METAL CHIP 47K 5% 1/10W
R029 1-216-809-11 METAL CHIP 100 5% 1/10W
R037 1-216-834-11 METAL CHIP 12K 5% 1/10W
R038 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R045 1-216-813-11 METAL CHIP 220 5% 1/10W
R052 1-216-864-11 SHORT CHIP 0
R053 1-216-864-11 SHORT CHIP 0
R054 1-216-864-11 SHORT CHIP 0
R055 1-216-864-11 SHORT CHIP 0
************************************************************
POWER SW PT RF
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
To Next Page
