Sony SCD-CE595 - SE-130 Board Components and Accessories

33
SCD-CE595
Ref. No. Part No. Description Remark
A-6060-642-A SE-130 BOARD
************
< CONNECTOR >
CN101 1-750-243-11 SOCKET, CONNECTOR 6P
CN102 1-573-383-11 PIN, CONNECTOR (PC BOARD) 2P
< PHONT SENSOR >
PH101 8-749-017-45 SENSOR, PHONT RPR-220C1N
PH102 6-600-072-01 IC RPI-392
************************************************************
MISCELLANEOUS
**************
56 1-828-334-11 WIRE (FLAT TYPE) (13 CORE)
0 104 1-777-071-43 CORD, POWER (AEP,UK)
0 104 1-783-531-32 CORD, POWER (US,CND)
207 1-829-172-11 WIRE (FLAT TYPE) (31 CORE)
0 216 A-1067-676-A DEVICE, OPTICAL (DBU-3)
218 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
M901 1-541-632-12 MOTOR, DC
RE901 1-418-746-11 ENCODER, ROTARY
0 T101 1-443-286-11 TRANSFORMER, POWER (US,CND)
0 T101 1-443-287-11 TRANSFORMER, POWER (AEP,UK)
ACCESSORIES
************
1-478-636-11 COMMANDER, STANDARD (RM-SX800)
1-790-735-12 CORD, CONNECTION
2-103-393-11 MANUAL, INSTRUCTION (ENGLISH)(US)
2-103-393-21 MANUAL, INSTRUCTION
(FRENCH, ENGLISH)(CND)
2-103-393-31 MANUAL, INSTRUCTION
(GERMAN, SPANISH, FRENCH, ENGLISH)(AEP,UK)
2-103-393-41 MANUAL, INSTRUCTION
(ITALIAN, DUTCH, POLISH, SWEDISH)(AEP)
SE-130
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
