7-9
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C405 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C421 1-124-589-11 ELECT 47uF 20% 16V
C422 1-124-589-11 ELECT 47uF 20% 16V
C423 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C424 1-164-159-21 CERAMIC 0.1uF 50V
C501 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C502 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C503 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C504 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C506 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C507 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C509 1-126-160-11 ELECT 1uF 20% 50V
C510 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C511 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C512 1-126-160-11 ELECT 1uF 20% 50V
C513 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C560 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C561 1-126-935-11 ELECT 470uF 20% 6.3V
C563 1-126-967-11 ELECT 47uF 20% 16V
C564 1-164-232-11 CERAMIC CHIP 0.01uF 50V
! C600 1-104-705-11 FILM 0.1uF 20% 250V
! C601 1-113-920-11 CERAMIC 0.0022uF 20% 250V
! C601 1-115-385-11 CERAMIC 0.0022uF 20% 125V
! C602 1-119-911-51 CERAMIC 470PF 10% 250V
! C603 1-119-911-51 CERAMIC 470PF 10% 250V
! C604 1-119-912-51 CERAMIC 1000PF 20% 250V
C605 1-119-882-41 ELECT (BLOCK) 120uF 20% 200V
C606 1-107-905-11 ELECT 4.7uF 20% 50V
C607 1-113-681-11 FILM 0.033uF 10% 400V
C608 1-162-558-11 CERAMIC 100PF 10% 2KV
C610 1-137-374-11 FILM 0.047uF 5% 50V
C611 1-137-374-11 FILM 0.047uF 5% 50V
C612 1-126-160-11 ELECT 1uF 20% 50V
C613 1-111-016-11 ELECT 0.0012F 20% 10V
C614 1-115-789-11 ELECT 0.001F 20% 25V
C615 1-126-967-11 ELECT 47uF 20% 50V
C616 1-126-941-11 ELECT 470uF 20% 25V
C617 1-126-935-11 ELECT 470uF 20% 16V
C618 1-126-934-11 ELECT 220uF 20% 16V
C619 1-124-248-00 ELECT 22uF 20% 35V
C620 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C621 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C622 1-128-131-11 ELECT 22uF 20% 50V
C623 1-126-967-11 ELECT 47uF 20% 16V
C624 1-126-967-11 ELECT 47uF 20% 16V
C625 1-126-967-11 ELECT 47uF 20% 16V
C626 1-126-965-11 ELECT 22uF 20% 50V
C627 1-126-965-11 ELECT 22uF 20% 50V
C628 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C629 1-124-234-00 ELECT 22uF 20% 16V
C701 1-126-967-11 ELECT 47uF 20% 16V
C706 1-126-963-11 ELECT 4.7uF 20% 50V
C707 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C708 1-126-933-11 ELECT 100uF 20% 16V
C709 1-126-933-11 ELECT 100uF 20% 16V
C710 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C711 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
(MONO)
C712 1-126-933-11 ELECT 100uF 20% 16V
C713 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C733 1-126-160-11 ELECT 1uF 20% 50V
C735 1-126-964-11 ELECT 10uF 20% 50V
(HiFi)
C736 1-126-967-11 ELECT 47uF 20% 16V
(HiFi)
C980 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(688HF)
C981 1-124-589-11 ELECT 47uF 20% 16V
(688HF)
C982 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(688HF)
C983 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(688HF)
C984 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(688HF)
C985 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
(688HF)
C986 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(688HF)
< PIN JACK >
CJ570 1-779-010-11 JACK, PIN 4P (LINE 1 IN/OUT) (MONO)
CJ570 1-779-011-11 JACK, PIN 6P (LINE 1 IN/OUT) (HiFi)
< CONNECTOR >
CN101 1-779-724-11 CONNECTOR, BOARD TO BOARD 5P
CN102 1-779-723-11 CONNECTOR, BOARD TO BOARD 9P
* CN103 1-766-716-11 CONNECTOR, BOARD TO BOARD 3P
CN161 1-506-468-11 PIN, CONNECTOR 3P
CN260 1-563-585-11 CONNECTOR, FLEXIBLE 8P (MONO)
CN260 1-766-986-11 CONNECTOR, FFC/FPC 13P (HiFi)
* CN261 1-560-892-00 PIN, CONNECTOR 4P
CN301 1-506-469-11 PIN, CONNECTOR 4P
CN302 1-506-468-11 PIN, CONNECTOR 3P
* CN341 1-560-891-00 PIN, CONNECTOR 3P (HiFi)
CN401 1-506-469-11 PIN, CONNECTOR 4P
(EXCEPT L57,L58,L77HF,L78HF,X50)
CN401 1-506-474-11 PIN, CONNECTOR 9P
(L57,L58,L77HF,L78HF,X50)
CN423 1-506-469-11 PIN, CONNECTOR 4P (L57,L58,X50)
CN423 1-506-470-11 PIN, CONNECTOR 5P (688HF,L77HF,L78HF)
CN600 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< JACK >
CNJ980 1-779-013-11 JACK, MINIATURE (CONTROL S OUT)(688HF)
< DIODE >
D103 8-719-048-26 DIODE GL528V1
D109 8-719-200-82 DIODE 11ES2
D161 8-719-200-82 DIODE 11ES2
D162 8-719-200-82 DIODE 11ES2
D382 8-719-048-07 DIODE M1MA151WKT1 (MONO)
D383 8-719-048-07 DIODE M1MA151WKT1 (MONO)
D405 8-719-056-07 DIODE SLR-342MC3F
D501 8-719-911-19 DIODE 1SS119
D560 8-719-109-74 DIODE RD4.3ES-B1
D600 8-719-051-93 DIODE DF06M-6031
MA-317
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
